OLEUM TECH.GR.I WITH 20% FREE SO3 (MIN) TO SPECN:IS:1089 OF 1986 (2nd REVISION) REAFFIRMED 2015.TO CONFIRM WITH ADDL.REQT FOR EXPLOSIVES INDUSTRY-Cl.3.3
FOIL TIN LEAD SPECN : JSS 9535-06:2010 (REV.NO.2) REAFFIRMED 2016 DC NO.6002-ME DT.24-09-2016 FOR THICKNESS 0.05MM SIZE OF THE STRIP-WIDTH-120MM, THICKNESS-0.05MM ANDLENGTH ADJUSTED TO 60 GRAM.
UNVARNISHED HOLLOW PAPER TUBE SIZE 800 MM LONG X 28 MM PLUS OR MINUS 1MM INTERNAL DIA,BOTH ENDS OPEN SPECN:CF 12.5 DT.17.1.95 WITH CORRECTION SLIP 12.5.1&12.5.2 CFA SKETCH NO.765 DATED. 2.12.88.
CAMBRIC COTTON DYED OLIVE GREEN 915 MM WIDE (36") IS COLOUR CODE 220 OF IS:5-2007 (SIXTH REVISION),RAF-2017 FOR OLIVE GREEN SPECIFICATION IS:5088-1982 (FIRST REVISION) WITH AMENDMENT NO.2 REAFFIRMED 2017(VARIETY NO.2)
CAMBRIC COTTON DYED SIGNAL RED 1117.6 MM (44") ISC COLOUR CODE 537 OF IS:5-2007 (Rev 6th,RAF 2017) FOR SIGNAL RED SPECN : IS:5088-1982 (FIRST REVISION) WITH AMENDMENT NO.2 REAFFIRMED 2017 (VARIETY NO.2)
CAMBRIC COTTON DYED AZURE BLUE 44" WIDE ISC NO:104OF IS:5/2007 FOR AZURE BLUE (SIXTH REVISION)RAF-2017 TO SPEN:IS: 5088 OF 1982 (FIRST REVISION) WITH AMENDMENT NO.2 REAFFIRMED 2017 (VARIETY NO.2)
CAMBRIC COTTON DYED SIGNAL RED 915 MM WIDE (36") ISC COLOUR CODE 537 OF IS: 5-2007 (SIXTH REVISION) FOR SIGNAL RED. SPECN:IS:5088 OF 1982(FIRST REVISION)WITH AMENDMENT NO.2 REAFFIRMED 2017 (VARIETY NO.2)
CASES C-128 MK-13 (NEW) WITHOUT PARTITION AND GROOVES AS PER SPECN/DRG.
Specification
CASES C-128 MK-13 (NEW) WITHOUT PARTITION AND GROOVES AS PER SPECN/DRG. PARTICULARS GIVEN BELOW. DRAWING:IA 1031 DC 36234-A DT: 04-02-1997 AND SPECN: IA948 ( A,F ) DC 36081-A READ WITH AIDE MEMOIRE - W/4.
BAGS CALICO FOR 40 KG M.T PROPELLANTS MADE OUT OF CALICO CLOTH AND AS PER CFA DRG NO.1037 DATED 24.12.2013 SPECN-IS-5088-1982 (FIRST REV) WITH AMENDMENT NO.2 OCT 1996 REAFD 2017-FOR CLOTH
CALICO BAG (20 KG CAPACITY) TO CFA SKETCH NO:932. DT.19.9.2001 WITH AMENDMENT NO.2 FOR BAG SPECN.IS-5088-1982 (FIRST REV)WITH AMENDMENT NO.2 OCT 1996 REAFD. 2017- FOR CLOTH
SPIRIT RECTIFIED TO SPECN IS:323-2009 (II REVISION REAFFIRMED 2014 DC NO.5009-ME DT.07.01.2011 DENATURED WITH 0.5% OF ACETONE TO SPECN. IS: 4117/ 2008 (SECOND REVISION) REAFFIRMED 2014
CALCIUM CARBONATE FOR EXPLOSIVES TYPE II PRECIPITATED MATERIAL RETAINED ON 90 MICRON IS SIEVE - NIL (PERCENT BY MASS) FOR USE IN PROPELLANTS SPECN: IS 7633 - 1982 REAFFIRMED 2016. (FIRST REVISION) AMENDMENT NO. 1 DC 5372-ME DT.28-07-2015
ALUMINIUM ALLOY AL ZN 4, 5 MG 1F 35 DIN 1725/1 SPECN.EXTRUDED HOLLOW PROFILE IN THE LENGTH OF 3870 +20MM FOR RG AS PER DRG. NO. IM0584 & SCOPE OF SUPPLY AS PER ANNEXURE 'A'
Specification
ALUMINIUM ALLOY AL ZN 4, 5 MG 1F 35 DIN 1725/1 SPECN.EXTRUDED HOLLOW PROFILE IN THE LENGTH OF 3870 +20MM FOR RG AS PER DRG. NO. IM0584 & SCOPE OF SUPPLY AS PER ANNEXURE 'A'
ALUMINIUM ALLOY AL ZN 4, 5 MG 1F 35 DIN 1725/1 SPECN. EXTRUDED HOLLOW PROFILE IN THE LENGTH OF 4850 + 20MM FOR MG AS PER DRG. NO. IM0584 & SCOPE OF SUPPLY AS PER ANNEXURE 'A' 6076450584
Specification
ALUMINIUM ALLOY AL ZN 4, 5 MG 1F 35 DIN 1725/1 SPECN. EXTRUDED HOLLOW PROFILE IN THE LENGTH OF 4850 + 20MM FOR MG AS PER DRG. NO. IM0584 & SCOPE OF SUPPLY AS PER ANNEXURE 'A' 6076450584
ASSEMBLY OF CSK FITTED BOLT M10 X 35MM CAT-1105 TO DRG NO. IMPD0993, WASHER DIA 11.5 TO DRG. NO.IMPD0994, HEX NUT M-10 TO DRG. NO. IMPD0995 AND LOCK NUT M10 FOR SR. NO. 1 TO DRG. IMPD 0996.
Specification
ASSEMBLY OF CSK FITTED BOLT M10 X 35MM CAT-1105 TO DRG NO. IMPD0993, WASHER DIA 11.5 TO DRG. NO.IMPD0994, HEX NUT M-10 TO DRG. NO. IMPD0995 AND LOCK NUT M10 FOR SR. NO. 1 TO DRG. IMPD 0996.
1. Chemical & Mechanical properties as per std. given drawing.
2. Dimensional inspection, for all dimensions given in the drawing & other parameter which are mentioned in relevant drawing.
70
40000
Number
17462
110180250
Ordnance Parachute Factory
The General Manager,
Kanpur
Kanpur
Kanpur, Uttar Pradesh
208004
Oil Micronised Graphite Shell Forging Lubricant as per IS: 14384:1996 (For Heavy Duty Application Under Clause No. 4.3 Table-2); Graphite Content:13 to 15% by Mass Graphite Particle Size: Upto 10 Microns: Minimum 98% Graphite Particle Size Greater Than 60 Microns: Nil
Specification
Oil Micronised Graphite Shell Forging Lubricant as per IS: 14384:1996 (For Heavy Duty Application Under Clause No. 4.3 Table-2); Graphite Content:13 to 15% by Mass Graphite Particle Size: Upto 10 Microns: Minimum 98% Graphite Particle Size Greater Than 60 Microns: Nil
Drawing no.
Manufacturing Technology
Firm should have manufacturing facility for the production of Oil Micronised Graphite Shell Forge Lube Oil.
The firm must have supplied forge lube oil to any Govt. Sector/PSU in last 07 years. The performance certificate of that supply has to be submitted.
Firm should submit details of process followed for manufacturing of the item in the form of process flow Chart.
Firm should submit quality plan for manufacturing of the item for assuring of the quality of the tendered item.
Firm should have enclosed in house facilities for inspection testing or tie up with NABL lab to mesure Viscosity, Ash Content and fixed carbon% in Oil.
IS:1461-1984 Second Revision (Reaffirmed-2003) and Supplementary Scheduled no. CQA (GS)/SS/346(b)
Except that: (i) Material shall be polyester.
(ii) Design & Dimensions: As per Drawing Enclosed (Drg. No. OCFAV/Button/002).
(iii) In app. Feel, Finish and all other resp. not defi. in this spec. Button shall confirm to the corres. sealed sample held in the cust. of the contro. customer service centre, OCF Avadi.
