Facility to apply for multiple items against multiple advertisement introduced. For details Click here || For any system/application related issues, please send the details of the issue to mail id: ofb.support@in.experis.com with a copy to the OFB mail id : ofbqcvrcell.ofb@ofb.gov.in

Items open for Registration

Search

Reset

Advertisement No.

Factory

Location

Items

AFK/2020/01

Ammunition Factory Khadki

The Cheif General Manager
Kirkee
Kirkee
Maharastra
411003

Name	Code	Quantity	Approx Value	Select
HEAD INTENSIFIER TUBE ASSEMBLY Description HEAD INTENSIFIER TUBE ASSEMBLY TO DRG. NO. IRW 4 SA Specification DRG. NO. IRW 4 SA Drawing no. Manufacturing Technology As per drawing and specification Manufacturing_Tech.pdf Testing / Inspection Facility As per Drawing and specification	60	NOT SPECIFIED Number
120145331 BRASS STRIP 0.58 MM PLUS/MINUS 0.025MM THICK X 35.6 MM PLUS/MINUS 0.25 MM WIDE Physical Verification needed Description BRASS STRIP 0.58 MM PLUS/MINUS 0.025MM THICK X 35.6 MM PLUS/MINUS 0.25 MM WIDE,ANNEALED HARDNESS 55 TO 75 HV,SPECN-JSS-9535-02-2019 REV.NO.5 THICKNESS VARIATION ACROSS WIDTH NOT TO EXCEED 0.005 MM,MATERIAL SHOULD BE FREE FROM ANISOTROPHY DEFECT.WEIGHT OF COIL 7KG MAX (L.F.NO.0717590200) (MAT.CODE.120145331) Specification SPECN-JSS-9535-02-2019 REV.NO.5 THICKNESS VARIATION ACROSS WIDTH NOT TO EXCEED 0.005 MM,MATERIAL SHOULD BE FREE FROM ANISOTROPHY DEFECT.WEIGHT OF COIL 7KG MAX Drawing no. Manufacturing Technology AS PER SPECIFICATION Manufacturing_Tech.pdf Testing / Inspection Facility AS PER SPECIFICATION	07	Not specified Kilogram

190137 TUNGSTEN POWDER

High Energy Projectile Factory

The Cheif General Manager
Trichy
Trichy
Trichy, Tamil Nadu
620025

Name	Code	Quantity	Approx Value	Select
FORGED AND HEAT TREATED BASE BLEED MOTOR TO OFAJ DRG NO. F-453E FOR 155MM ERFB (BB). Physical Verification needed Description FORGED AND HEAT TREATED BASE BLEED MOTOR TO OFAJ DRG NO. F-453E FOR 155MM ERFB (BB). Specification a) OFAJ Drawing No. F-453-E b) Specification: ASTM B221M – 07 c) MI (Monitoring Instructions) No.: HAPP/QA/SC/BBM/001, DOI: 25/10/2025, Is. No. 01, Rev. No. 00 DRAWING _SPEC_MI_-_of_forged_blanks_for_Base_Bleed_(BB)_MOTOR.pdf Drawing no. DRAWING _SPEC_MI_-_of_forged_blanks_for_Base_Bleed_(BB)_MOTOR.pdf Manufacturing Technology OFAJ DRG NO. F-453E FOR 155MM ERFB (BB). DRAWING _SPEC_MI_-_of_forged_blanks_for_Base_Bleed_(BB)_MOTOR.pdf Testing / Inspection Facility As per MI (Monitoring Instructions) No.: HAPP/QA/SC/BBM/001, DOI: 25/10/2025, Is. No. 01, Rev. No. 00	01	2100 Number
1010180050 WHITE COLOUR POLY EURATHENE PAINT CHEMTHANE-3300 BASE WITH ITS COMPONENTS Description 1010180050 WHITE COLOUR POLY EURATHENE PAINT CHEMTHANE-3300 BASE WITH ITS COMPONENTS VIZ.HARDNER & THINNER FOR ROCKET RGB-60 AS PER SPECIFICATION PROVIDED BY CNA(OF)VIDE LETTER NO.PI/9206/YDB-60 (IND)DT.15 JUL 20 Specification AS PER SPECIFICATION PROVIDED BY CNA(OF)VIDE LETTER NO.PI/9206/YDB-60 (IND)DT.15 JUL 20 Drawing no. Manufacturing Technology AS PER SPECIFICATION Manufacturing_Tech.pdf Testing / Inspection Facility AS PER SPECIFICATION	10	NOT SPECIFIED Litre

2019000155

Ordnance Factory Dehu Road

The Cheif General Manager
Dehu Road
Dehu Road
Maharashtra
412101

Name	Code	Quantity	Approx Value	Select
Set of 11 Components consisting (empty) for Marker Man Over Board Description SET OF COMPONENTS CONSISTING OF 11 ITEMS (EMPTY) TO DRG. NO. NAI (P) 511(PROV) FOR MARKER MAN OVER BOARD Specification SET OF COMPONENTS CONSISTING OF 11 ITEMS (EMPTY) TO DRG. NO. NAI (P) 511(PROV) FOR MARKER MAN OVER BOARD Drawing no. Manufacturing Technology as per specification/ drawing NO. NAI (P) 511(PROV) FOR MARKER MAN OVER BOARD mmob.PDF Testing / Inspection Facility as per specification/ drawing	62	120 Set
12014467 BRASS TUBES (SEAMLESS) OD 6MM PLUS MINUS 0.05 Description BRASS TUBES (SEAMLESS) OD 6MM PLUS MINUS 0.05, ID 5MM PLUS MINUS 0.05 MM OF TWO METER LENGTH TO SPECIFICATION JSS: -9535-02:2019 REV. 5 AND PHYSICAL PROPERTIES TO SPECN. IS 407-1981,(Third Rev) Reaffirmed 2021 HARDNESS 110-130 VPN (L.F.NO.0707257661) (MAT.CODE.12014467) Specification AS PER SPECIFICATION JSS: -9535-02:2019 REV. 5 AND PHYSICAL PROPERTIES TO SPECN. IS 407-1981,(Third Rev) Reaffirmed 2021 HARDNESS 110-130 VPN Drawing no. Manufacturing Technology AS PER SPECIFICATION Manufacturing_Tech.pdf Testing / Inspection Facility AS PER SPECIFICATION	07	NOT SPECIFIED Kilogram

PV/OFCH/ADV REGD/JAN-20/69

Ordnance Factory Chanda

The Cheif General Manager
Chanda
Chanda
Maharashtra
442501

Name	Code	Quantity	Approx Value	Select
CUP TO DRG NO TRD 1.1.3763 (REF NO 6160198) (I/C- 6191700305) Description CUP TO DRG NO TRD 1.1.3763 (REF NO 6160198) (I/C- 6191700305) Specification CUP TO DRG NO TRD 1.1.3763 (REF NO 6160198) (I/C- 6191700305) Drawing no. DRG NO TRD 1.1.3763 Manufacturing Technology AS PER SPECIFICATION PLANT_AND_MACHINERY.pdf Testing / Inspection Facility AS PER DRAWING	61	100000 Set
CUP 41-3 FOR IGNITING PRIMER MG 08 TO DRG NO OCT-84-407-77 AND CAP K 3-2 FOR IGINTING PRIMER MG 08 TO DRG NO OCT -84-407-77 (I/C- 6191700300) Description CUP 41-3 FOR IGNITING PRIMER MG 08 TO DRG NO OCT-84-407-77 AND CAP K 3-2 FOR IGINTING PRIMER MG 08 TO DRG NO OCT -84-407-77 Specification CUP 41-3 FOR IGNITING PRIMER MG 08 TO DRG NO OCT-84-407-77 AND CAP K 3-2 FOR IGINTING PRIMER MG 08 TO DRG NO OCT -84-407-77 Drawing no. DRG NO OCT -84-407-77 Manufacturing Technology AS PER SPECIFICATION PLANT_AND_MACHINERY.pdf Testing / Inspection Facility AS PER DRAWING	61	100000 Set

143MMETT19000734

Ordnance Factory Nalanda

The Cheif General Manager
PO. - Rajgir Dist. - Nalanda
Rajgir
Nalanda, Bihar
803116

Name	Code	Quantity
PLASTIC FILM SLEEVE Description PLASTIC FILM SLEEVE SPEC NO. OFN/SPEC/BMCS/M92/PFS/00, AS PER DRAWING NO. BMCS-M92-PFS-01 ,QAP NO. OFN/QAP/BMCS/M92/PFS/00 DATED 04/04/2024 REV. 00 AND MI NO. OFN/MI/BMCS/M92/PFS/00 REV. 00 DATED 09/12/2024 Specification PLASTIC FILM SLEEVE SPEC NO. OFN/SPEC/BMCS/M92/PFS/00, AS PER DRAWING NO. BMCS-M92-PFS-01 ,QAP NO. OFN/QAP/BMCS/M92/PFS/00 DATED 04/04/2024 REV. 00 AND MI NO. OFN/MI/BMCS/M92/PFS/00 REV. 00 DATED 09/12/2024 spec_sleeve.pdf Drawing no. drawing_sleeve.pdf Manufacturing Technology AS PER QAP manuf-sleeve.pdf Testing / Inspection Facility AS PER QAP	64	95627 Number
BOX WOOD FOR TRAINING SMOKE GENERATOR Description BOX WOOD TO DRG NO ERDL/1084 DET NO.1 and DET NO.2 SHT no.2 PAINTED WITH READY MIXED PAINT, QUICK DRYING MATT FOR GENERAL PURPOSE SERVICE BROWN (IS:5:2007) (6TH REV) RA 2012 ISC 499 TO SPECN : IS 168 1993 (3RD REV) DC 5035 ME DT 14.11.2011 RA 2012 Specification BOX WOOD TO DRG NO ERDL/1084 DET NO.1 and DET NO.2 SHT no.2 PAINTED WITH READY MIXED PAINT, QUICK DRYING MATT FOR GENERAL PURPOSE SERVICE BROWN (IS:5:2007) (6TH REV) RA 2012 ISC 499 TO SPECN : IS 168 1993 (3RD REV) DC 5035 ME DT 14.11.2011 RA 2012 Drawing no. Manufacturing Technology AS PER SPECIFICATION drg_bw.pdf Testing / Inspection Facility AS PER SPECIFICATION	62	77 Number
LOCKING PIN FOR 81 MM ILLG Description CQA(A) 2345(c)[Drg. No. ARDE- 1965 DET. 26 , Part No. ITV 115] Specification CQA(A) 2345(c)[Drg. No. ARDE- 1965 DET. 26 , Part No. ITV 115] Drawing no. Manufacturing Technology AS PER SPECIFICATION drg.pdf Testing / Inspection Facility AS PER SPECIFICATION	62	460000 Number
SELF ADHESIVE TAPE FOR BMCS Description SELF ADHESIVE TAPE FOR BMCS SPEC. NO. – OFN/SPEC/BMCS/M91/M92/SAT/00 AS PER DRAWING NO.BMCS-M91-M92-SAT-01 , AS PER QAP NO. OFN/QAP/BMCS/M91/M92/SAT/00 DATED 13.04.2024 AND MI NO. OFN /MI/BMCS/M91/M92/SAT/00 REV 00 DATED 06.12.2024 Specification SELF ADHESIVE TAPE FOR BMCS SPEC. NO. – OFN/SPEC/BMCS/M91/M92/SAT/00 AS PER DRAWING NO.BMCS-M91-M92-SAT-01 , AS PER QAP NO. OFN/QAP/BMCS/M91/M92/SAT/00 DATED 13.04.2024 AND MI NO. OFN /MI/BMCS/M91/M92/SAT/00 REV 00 DATED 06.12.2024 SPEC_TAPE.pdf Drawing no. DRAWING_TAPE.pdf Manufacturing Technology AS PER QAP MANUF_TAPE.pdf Testing / Inspection Facility AS PER QAP	25	140850 Number
BORE WEAR REDUCING LINER (BWRL) Description BORE WEAR REDUCING LINER (BWRL), AS PER SPECIFICATION NO. OFN/SPEC/BMCS/M92/BWRL/00, AS PER DRAWING No.BMCS-M92-BWRL-01, AS PER QAP NO. OFN/QAP/BMCS/M92/BWRL/00 DATED 29.03.2024 & AS PER MI NO.OFN/MI/BMCS/M92/BWRL/00 DATED 06.12.2024 Specification BORE WEAR REDUCING LINER (BWRL), AS PER SPECIFICATION NO. OFN/SPEC/BMCS/M92/BWRL/00, AS PER DRAWING No.BMCS-M92-BWRL-01, AS PER QAP NO. OFN/QAP/BMCS/M92/BWRL/00 DATED 29.03.2024 & AS PER MI NO.OFN/MI/BMCS/M92/BWRL/00 DATED 06.12.2024 SPEC_BWRL.pdf Drawing no. DRAWING_BWRL.pdf Manufacturing Technology AS PER QAP MANUF_BWRL.pdf Testing / Inspection Facility AS PER QAP	64	107729 Number
BARRIER BAG FOR M91 & M92 Description BARRIER BAG FOR M91 & M92-OFN/ SPEC/ BMCS/ M91/ M92/ BB/00, AS PER DRAWING NO. BMCS-M91-M92-BB-02 and QAP No. OFN/QAP/BMCS/M92/M91/BB/00 DATED 04/04/2024 Specification BARRIER BAG FOR M91 & M92-OFN/ SPEC/ BMCS/ M91/ M92/ BB/00, AS PER DRAWING NO. BMCS-M91-M92-BB-02 and QAP No. OFN/QAP/BMCS/M92/M91/BB/00 DATED 04/04/2024 spec_bb.pdf Drawing no. drawing_bb.pdf Manufacturing Technology AS PER QAP manuf_bb.pdf Testing / Inspection Facility AS PER QAP	64	155467 Number
PLASTIC FILM BAG FOR BMCS Description PLASTIC FILM BAG FOR BMCS, SPECIFICATION NO. OFN/SPEC/BMCS/M91/M92/PFB/00, AS PER DRAWING No.BMCS-M91-M92-PFB-01 , QAP NO. OFN/QAP/BMCS/M92/M91/PFB/00 DATED 04.04.2024 REV. 00 & AS PER MI NO.OFN/MI/BMCS/M91/M92/PFB/00 DATED 09.12.2024 Specification PLASTIC FILM BAG FOR BMCS, SPECIFICATION NO. OFN/SPEC/BMCS/M91/M92/PFB/00, AS PER DRAWING No.BMCS-M91-M92-PFB-01 , QAP NO. OFN/QAP/BMCS/M92/M91/PFB/00 DATED 04.04.2024 REV. 00 & AS PER MI NO.OFN/MI/BMCS/M91/M92/PFB/00 DATED 09.12.2024 pfb_spec.pdf Drawing no. pfb_drawing.pdf Manufacturing Technology AS PER QAP manuf_pfb.pdf Testing / Inspection Facility AS PER QAP	64	131445 Number
IGNITER BAG (FOR M-92) Description IGNITER BAG (FOR M-92) AS PER QAP No. OFN/QAP/BMCS/M92/IB/00 Dated 04.04.2024, SPECIFICATION No. OFN/SPEC/RAW MAT/M92/IB/00 AND DRAWING NO.BMCS-M92-IB-01, BMCS-M92-IB-02, BMCS-M92-IB-04 & AS PER MI NO.OFN/MI/BMCS/M92/IB/00 REV 00 DATED 09.12.2024 Specification IGNITER BAG (FOR M-92) AS PER QAP No. OFN/QAP/BMCS/M92/IB/00 Dated 04.04.2024, SPECIFICATION No. OFN/SPEC/RAW MAT/M92/IB/00 AND DRAWING NO.BMCS-M92-IB-01, BMCS-M92-IB-02, BMCS-M92-IB-04 & AS PER MI NO.OFN/MI/BMCS/M92/IB/00 REV 00 DATED 09.12.2024 in_spec.pdf Drawing no. igniter_drawing.pdf Manufacturing Technology AS PER QAP manuf_.pdf Testing / Inspection Facility AS PER QAP	63	69546 Number
TIN FOIL Description TIN FOIL, AS PER SPECIFICATION No. OFN/SPEC/BMCS/M91/M92/TF/00(APPENDIX -05), DRAWING NO. BMCS-M91-M92-TF-01 , QAP No. OFN/QAP/BMCS/M91/M92/TF/00 DATED 10.04.2024 & AS PER MI NO.OFN/MI/BMCS/M91/M92/TF/00 DATED 04.12.2024 Specification TIN FOIL, AS PER SPECIFICATION No. OFN/SPEC/BMCS/M91/M92/TF/00(APPENDIX -05), DRAWING NO. BMCS-M91-M92-TF-01 , QAP No. OFN/QAP/BMCS/M91/M92/TF/00 DATED 10.04.2024 & AS PER MI NO.OFN/MI/BMCS/M91/M92/TF/00 DATED 04.12.2024 tin__spec.pdf Drawing no. tin_drawing.pdf Manufacturing Technology AS PER QAP tin_mnf.pdf Testing / Inspection Facility AS PER QAP	64	1323 Kilogram
ELECTRONIC PERCUSSION FUZE FOR SHELL 155 MM (WITHOUT BOOSTER PALLET) Description ELECTRONIC PERCUSSION FUZE FOR SHELL 155 MM (WITHOUT BOOSTER PALLET) AS PER SPECIFICATION NO.3094/PYRO/R&D DATED 30.09.2025 Specification ELECTRONIC PERCUSSION FUZE FOR SHELL 155 MM (WITHOUT BOOSTER PALLET) AS PER SPECIFICATION NO.3094/PYRO/R&D DATED 30.09.2025 Drawing no. Manufacturing Technology AS PER TECHNICAL SPECIFICATION EPF_Tech_spec.pdf Testing / Inspection Facility AS PER TECHNICAL SPECIFICATION	62	500 Number
SHELL 155 MM EMPTY ASSY Description A). SHELL EMPTY ASSY(M2)TO DRG. NO. 2439A11001 ASSY AS PER NOTE 1, 2 & 3 AS MENTIONED B). ADAPTER BOAT TAIL TO DRG. NO. 2440A10002.DC-37535-A, 22.10.19 C). BOAT TAIL MACHINED TO DRG. NO. 155-1150.DC-37546-A, 01.02.20. PLUG LIFTING M9039A1 TO DRG. NO. 2439A00018 DC-37535-A, 22.10.19 Specification A). SHELL EMPTY ASSY(M2)TO DRG. NO. 2439A11001 ASSY AS PER NOTE 1, 2 & 3 AS MENTIONED B). ADAPTER BOAT TAIL TO DRG. NO. 2440A10002.DC-37535-A, 22.10.19 C). BOAT TAIL MACHINED TO DRG. NO. 155-1150.DC-37546-A, 01.02.20. PLUG LIFTING M9039A1 TO DRG. NO. 2439A00018 DC-37535-A, 22.10.19 SHELL_155_MM_EMPTY_ASSY.pdf Drawing no. DETAILED DRAWINGS / SPECIFICATIONS MAY BE OBTAINED FROM CQA (A), KHADKI, PUNE SHELL_155_MM_EMPTY_ASSY.pdf Manufacturing Technology AS PER SPECIFICATION & DRAWINGS FORGING, MACHINING DETAILED DRAWINGS / SPECIFICATIONS MAY BE OBTAINED FROM CQA (A), KHADKI, PUNE DETAILED DRAWINGS / SPECIFICATIONS MAY BE OBTAINED FROM CQA (A), KHADKI, PUNE DETAILED DRAWINGS / SPECIFICATIONS MAY BE OBTAINED FROM CQA (A), KHADKI, PUNE SHELL_155_MM_EMPTY_ASSY.pdf Testing / Inspection Facility AS PER SPECIFICATION & DRAWINGS DETAILED DRAWINGS / SPECIFICATIONS MAY BE OBTAINED FROM CQA (A), KHADKI, PUNE DETAILED DRAWINGS / SPECIFICATIONS MAY BE OBTAINED FROM CQA (A), KHADKI, PUNE DETAILED DRAWINGS / SPECIFICATIONS MAY BE OBTAINED FROM CQA (A), KHADKI, PUNE DETAILED DRAWINGS / SPECIFICATIONS MAY BE OBTAINED FROM CQA (A), KHADKI, PUNE	63	1000 Number

EOI13/PV/M1

Ordnance Factory Itarsi

The Cheif General Manager
Itarsi
Itarsi
Madhya Pradesh
461122

Name	Code	Quantity	Approx Value	Select
Guanidine Nitrate. Physical Verification needed Description Guanidine Nitrate as per Specification No.: JSS 6810-95:2023 (Rev. No. 5) DC No.- 6673-ME Dt. 08/07/2024 Specification Specification No.: JSS 6810-95:2023 (Rev. No. 5) DC No.- 6673-ME Dt. 08/07/2024 Drawing no. Manufacturing Technology As per attached document Manufacturing_Technology_Testing_Facilities.pdf Testing / Inspection Facility As per attached document	1001256000	207896 Kilogram

OFBA/196034

Ordnance Factory Bhandara

The Cheif General Manager
Bhandara
Bhandara
Maharashtra
441906

Name	Code	Quantity
REEL 1A/L PACKAGE AMMN 79-A TO DRG NO. OFBA/CX/54 DT. 8.4.93 AMD.DT: 31.07.20. ALTERNATE METHODE. PLYWOOD GENERAL PURPOSE MR GRADE TYPE BB TO IS: 303-1989 (REV-3)(REAFFIRM2018) STEEL RIB IS 1079-2017 (REV-7) (REAFFIRM2022) OR IS513 (PT-1)-2016. REV- Description REEL 1A/L PACKAGE AMMN 79-A TO DRG NO. OFBA/CX/54 DT. 8.4.93 AMD.DT: 31.07.20. ALTERNATE METHODE. PLYWOOD GENERAL PURPOSE MR GRADE TYPE BB TO IS: 303-1989 (REV-3)(REAFFIRM2018) STEEL RIB IS 1079-2017 (REV-7) (REAFFIRM2022) OR IS513 (PT-1)-2016. REV-6. VARNISH A/D AMMN. TO SPECN. IND/ME/719 (d) DC3754-ME, DT 12.12.02. Specification SPECN. IND/ME/719 (d) DC3754-ME, DT 12.12.02. QAP_REEL0001.pdf Drawing no. DRG NO. OFBA/CX/54 DT. 8.4.93 AMD.DT: 31.07.20. REEL_DRG_.pdf Manufacturing Technology MSME QAP_REEL0001.pdf Testing / Inspection Facility NABL/ Govt. Lab reports for each components.	65	6000 Number
CRATE 5 A/L WIRE BOUND FOR PACKAGE AMM. 79A TO DRG. NO. OFBA/CX/55 DTS-16.08.94 AMMENDED ON 15.02.02 TRACED FROM CI (A)/AMN/754 PART NO ISV 326A DC (I) 30562-A SPECN.IA 948 (a. f ) DC 36081A. Description CRATE 5 A/L WIRE BOUND FOR PACKAGE AMM. 79A TO DRG. NO. OFBA/CX/55 DTS-16.08.94 AMMENDED ON 15.02.02 TRACED FROM CI (A)/AMN/754 PART NO ISV 326A DC (I) 30562-A SPECN.IA 948 (a. f ) DC 36081A. Specification SPECN.IA 948 (a. f ) DC 36081A. QAP_CRATE.pdf Drawing no. DRG. NO. OFBA/CX/55 DTS-16.08.94 AMMENDED ON 15.02.02 TRACED FROM CI (A)/AMN/754 PART NO ISV 326A DC (I) 30562-A Crate_5AL_Drg_merged.pdf Manufacturing Technology MSME QAP_CRATE.pdf Testing / Inspection Facility NABL / Govt. Lab. reports for each components	65	6000 Number
PLYWOOD C-26 BOX AS PER OFBA SPECIFICATION NO. 1.56 DTD. 09.02.2023 WITH DRAWING NO. OFBA/BT/120 ATTACHED. Description PLYWOOD C-26 BOX AS PER OFBA SPECIFICATION NO. 1.56 DTD. 09.02.2023 WITH DRAWING NO. OFBA/BT/120 ATTACHED. Specification OFBA SPECIFICATION NO. 1.56 DTD. 09.02.2023 PLY_C-26_SPEC.pdf Drawing no. DRAWING NO. OFBA/BT/120 PLY_C-26_SPEC.pdf Manufacturing Technology MSME PLY_C-26_SPEC.pdf Testing / Inspection Facility NABL / Govt. Lab reports for each components	22	3500 Number

0630/PV/TE/20180289 Dtd. 31-03-2019

Ordnance Factory Varangaon

The Cheif General Manager
Varangaon
Varangaon
Maharashtra
425308

Name	Code	Quantity
LEAD ANTIMONY ALLOY INGOT 98:2 Description JSS 9530-02-2020 (Fourth Revision) Specification JSS 9530-02-2020 (Fourth Revision) Drawing no. Manufacturing Technology Lead Antimony Alloy Melting Furnace JSS_9530-02-2020_(Fourth_Revision)_LEAD_ALLOY_RODS_FOR_BULLET_CORES.pdf Testing / Inspection Facility Spectroscopy	60	200 Metric tonne(1000kg)
LEAD ANTIMONY ALLOY INGOT Pb:Sb - 98:2 Description IS:1654-1992(THIRD REVISION), GRADE PBSB2 Specification IS:1654-1992(THIRD REVISION), GRADE PBSB2 Drawing no. Manufacturing Technology Lead Antimony Alloy Melting Furnace Lead_Antimony_IS.pdf Testing / Inspection Facility Spectroscopy	60	200 Metric tonne(1000kg)
Lead Antimony Alloy Wire Dia 4.22 mm (+/- 0.05 mm) With Sb 2% (+/-0.2%) Description Lead Antimony Alloy Wire Dia 4.22 mm (+/- 0.05 mm) With Sb 2% (+/-0.2%) Other Terms and Conditions as per OFV Specifications Dated 12/02/2025 Specification Lead Antimony Alloy Wire Dia 4.22 mm (+/- 0.05 mm) With Sb 2% (+/-0.2%) Other Terms and Conditions as per OFV Specifications Dated 12/02/2025 Drawing no. Manufacturing Technology Lead Antimony Alloy Melting Furnace Lead Antimony Alloy Billet Casting Lead Antimony Alloy Wire Extrusion Press Automatic Wire Reeling Machine specification_antimony.pdf Testing / Inspection Facility Spectroscopy Micrometer	60	20000 Kilogram
Lead Antimony Alloy Wire Dia 5.70 mm (+/- 0.05 mm) With Sb 2% (+/-0.2%) Description Lead Antimony Alloy Wire Dia 5.70 mm (+/- 0.05 mm) With Sb 2% (+/-0.2%) Other Terms and Conditions as per OFV Specifications Dated 12/02/2025 Specification Lead Antimony Alloy Wire Dia 5.70 mm (+/- 0.05 mm) With Sb 2% (+/-0.2%) Other Terms and Conditions as per OFV Specifications Dated 12/02/2025 Drawing no. Manufacturing Technology Lead Antimony Alloy Melting Furnace Lead Antimony Alloy Billet Casting Lead Antimony Alloy Wire Extrusion Press Automatic Wire Reeling Machine specification_antimony.pdf Testing / Inspection Facility Spectroscopy Micrometer	60	20000 Kilogram
Lead Antimony Alloy Wire Dia 5.80 mm (+/- 0.05 mm) With Sb 2% (+/-0.2%) Description Lead Antimony Alloy Wire Dia 5.80 mm (+/- 0.05 mm) With Sb 2% (+/-0.2%) Other Terms and Conditions as per OFV Specifications Dated 12/02/2025 Specification Lead Antimony Alloy Wire Dia 5.80 mm (+/- 0.05 mm) With Sb 2% (+/-0.2%) Other Terms and Conditions as per OFV Specifications Dated 12/02/2025 Drawing no. Manufacturing Technology Lead Antimony Alloy Melting Furnace Lead Antimony Alloy Billet Casting Lead Antimony Alloy Wire Extrusion Press Automatic Wire Reeling Machine specification_antimony.pdf Testing / Inspection Facility Spectroscopy Micrometer	60	50000 Kilogram
Lead Antimony Alloy Wire Dia 5.60 mm (+/- 0.05 mm) With Sb 2% (+/-0.2%) Description Lead Antimony Alloy Wire Dia 5.60 mm (+/- 0.05 mm) With Sb 2% (+/-0.2%) Other Terms and Conditions as per OFV Specifications Dated 12/02/2025 Specification Lead Antimony Alloy Wire Dia 5.60 mm (+/- 0.05 mm) With Sb 2% (+/-0.2%) Other Terms and Conditions as per OFV Specifications Dated 12/02/2025 Drawing no. Manufacturing Technology Lead Antimony Alloy Melting Lead Antimony Alloy Billet Casting Lead Antimony Alloy Wire Extrusion Press Automatic Wire Reeling Machine specification_antimony.pdf Testing / Inspection Facility Spectroscopy Micrometer	60	11000 Kilogram
Base Bleed Motor with Adaptor Physical Verification needed Description Base Bleed Motor with Adaptor Specification Base Bleed Motor with Adapter as per OFI technical specification no. 51/BBU/ (Motor & Adaptor)/GMP/OFI Dt. 15/09/2025 Drawing no. As per Drawing No. (1) for Base Bleed Motor: 02676-20001A203 dtd. 03/08/2007, (2) for Adaptor: 02676-20011A02 dtd. 03/08/2007 Manufacturing Technology As per attached document Manufacturing_Technology_Testing_Facilities_approved.pdf Testing / Inspection Facility As per attached document	2040751888	17614 Set

OFK/2019/05/IV/3

Ordnance Factory Khamaria

The Cheif General Manager
Khamaria
Khamaria
Madhya Pradesh
482005

Name	Code	Quantity	Approx Value	Select
FILLED FUZES WITH BODY ASSEMBLY & FRAGMENT JACKET (9911358911) Physical Verification needed Description FILLED FUZES WITH BODY ASSEMBLY & FRAGMENT JACKET Specification FILLED FUZES WITH BODY ASSEMBLY & FRAGMENT JACKET AS PER TBRL DRG.NO. TBRL/MMG-H/MK1/A00/R3.(9911358911) Drawing no. Manufacturing Technology TO BE UPLOADED DUMMYY.pdf Testing / Inspection Facility TO BE UPLOADED	99	320000 Number
PLASTIC PACKAGE FOR TAIL UNIT OF 1000 KG GP AS PER SPECN NO.DRDO-ARDE-ADM-GP-1000-02-2023 (LF- 9911358874) Physical Verification needed Description PLASTIC PACKAGE FOR TAIL UNIT OF 1000 KG GP AS PER SPECN NO.DRDO-ARDE-ADM-GP-1000-02-2023 Specification PLASTIC PACKAGE FOR TAIL UNIT OF 1000 KG GP AS PER SPECN NO.DRDO-ARDE-ADM-GP-1000-02-2023 OpenDocument_Text.pdf Drawing no. SPECN NO.DRDO-ARDE-ADM-GP-1000-02-2023 OpenDocument_Text.pdf Manufacturing Technology SPECN NO.DRDO-ARDE-ADM-GP-1000-02-2023 PLASTIC PACKAGE FOR TAIL UNIT OF 1000 KG GP AS PER SPECN NO.DRDO-ARDE-ADM-GP-1000-02-2023 PLASTIC PACKAGE FOR TAIL UNIT OF 1000 KG GP AS PER SPECN NO.DRDO-ARDE-ADM-GP-1000-02-2023 PLASTIC PACKAGE FOR TAIL UNIT OF 1000 KG GP AS PER SPECN NO.DRDO-ARDE-ADM-GP-1000-02-2023 PLASTIC PACKAGE FOR TAIL UNIT OF 1000 KG GP AS PER SPECN NO.DRDO-ARDE-ADM-GP-1000-02-2023 OpenDocument_Text.pdf Testing / Inspection Facility PLASTIC PACKAGE FOR TAIL UNIT OF 1000 KG GP AS PER SPECN NO.DRDO-ARDE-ADM-GP-1000-02-2023 PLASTIC PACKAGE FOR TAIL UNIT OF 1000 KG GP AS PER SPECN NO.DRDO-ARDE-ADM-GP-1000-02-2023 PLASTIC PACKAGE FOR TAIL UNIT OF 1000 KG GP AS PER SPECN NO.DRDO-ARDE-ADM-GP-1000-02-2023 PLASTIC PACKAGE FOR TAIL UNIT OF 1000 KG GP AS PER SPECN NO.DRDO-ARDE-ADM-GP-1000-02-2023 PLASTIC PACKAGE FOR TAIL UNIT OF 1000 KG GP AS PER SPECN NO.DRDO-ARDE-ADM-GP-1000-02-2023	99	21 Number

OFBL/ADV/33/STRAP TO DRG

Ordnance Factory Bolangir

The Cheif General Manager
Bolangir
Bolangir
Orissa
767770

Name	Code	Quantity
SHELL BODY WITH DRIVING BAND 107 TO TO DRG.NO.3060202 DC:36490-A DTD.19.11.1998 Physical Verification needed Description SHELL BODY WITH DRIVING BAND 107 TO TO DRG.NO.3060202DC:36490-ADTD.19.11.1998 AND SURFACETREATED AS PER DRG.NO.3060203 DC:36490-ADTD.19.11.98 EXTERNALLY PAINTED WITH PAINT OLIVE GREEN RAL 6003 MATT FINISH TO DEFENCE STANDARD:DEF STAN 80-25 ISSUE-5 2009(PAINT AMMUNITION FINISHING, STOVING& DIPPING TYPES).INTERNALLYOIL SEALED WITH LIFTING PLUG TO DRG.NO.5191856 DC NO.37595-A DTD.08.12.21 AND GASKET TO DRG.NO.6391043 DC NO.36695-A DTD. 08.08.2000, LOOSELY FITTED. Specification SHELL BODY WITH DRIVING BAND 107 TO TO DRG.NO.3060202DC:36490-ADTD.19.11.1998 AND SURFACETREATED AS PER DRG.NO.3060203 DC:36490-ADTD.19.11.98 EXTERNALLY PAINTED WITH PAINT OLIVE GREEN RAL 6003 MATT FINISH TO DEFENCE STANDARD:DEF STAN 80-25 ISSUE-5 2009(PAINT AMMUNITION FINISHING, STOVING& DIPPING TYPES).INTERNALLYOIL SEALED WITH LIFTING PLUG TO DRG.NO.5191856 DC NO.37595-A DTD.08.12.21 AND GASKET TO DRG.NO.6391043 DC NO.36695-A DTD. 08.08.2000, LOOSELY FITTED. Drawing no. Manufacturing Technology Shear cutting machine/Band saw for cutting billets having capacity minimum 15,000 Nos per month, Induction Furnace of capacity minimum 1000 KW for heating Billets, Hydraulic press for forging of capacity minimum 1000 MT, Press for nosing operation of capacity minimum 01 MT, Crimping Machine for Copper Band Crimping of capacity minimum 300 T, Hydraulic Pressure testing machine for capacity minimum 600 Bar, CNC machine for machining operation of capacity minimum 10,000 Nos. per month, MPI facility for capacity minimum 5,000 Amp, Seam Welding machine of capacity to weld minimum 10,000 Nos Shells per month, Ultrasonic machine for ultrasonic immersion method to cover all the portions of the shell volumetrically including the Flat bottom hole, Phosphating & Painting Facility @ minimum 10,000 Nos. shells per month, Shot blasting facility/machine, Quality control equipment for dimensional and quality checks. Manufacturing facility or Tie-up/MOU for Lifting Plug and Gasket shell_107_mod2_mfg.pdf Testing / Inspection Facility Hydraulic Pressure testing machine for capacity minimum 600 Bar, MPI facility for capacity minimum 5,000 Amp, Ultrasonic machine for ultrasonic immersion method to cover all the portions of the shell volumetrically including the Flat bottom hole, Quality control equipment for dimensional and quality checks.	62	54351 Number
BASE PLATE 8.5MM PART NO 404028661 LF 9911358414 Physical Verification needed Description BASE PLATE 8.5MM PART NO. 404028661 TO OEM DRG.NO.304059505 TRD DRG.NO.2.2.2527 Specification BASE PLATE 8.5MM PART NO. 404028661 TO OEM DRG.NO.304059505 TRD DRG.NO.2.2.2527 Drawing no. BASE PLATE 8.5MM PART NO. 404028661 TO OEM DRG.NO.304059505 TRD DRG.NO.2.2.2527 Manufacturing Technology as per file attached base_plate.png Testing / Inspection Facility as per file attached	99	14155 Number
CABLE TIE PART NO 4102077 LF 2101779000 Physical Verification needed Description CABLE TIE PART NO. 4102077 TO OEM DRG NO.304094816/TRD DRG NO.3.2.2674 Specification CABLE TIE PART NO. 4102077 TO OEM DRG NO.304094816/TRD DRG NO.3.2.2674 Drawing no. CABLE TIE PART NO. 4102077 TO OEM DRG NO.304094816/TRD DRG NO.3.2.2674 Manufacturing Technology (I) INJECTION MOULDING FACILITY (II) DIMENSION MEASURING FACILITY 2101779000.png Testing / Inspection Facility (III) RELEVANT INSPECTION AND TESTING FACILITY	21	4324 Number
PACKAGE TO DRG NO 08040002000000000 LF 9911358292 Physical Verification needed Description PACKAGE TO DRG.NO.ARDE 08040002000000000PB,DTD 14/05/2015. Specification PACKAGE TO DRG.NO.ARDE 08040002000000000PB,DTD 14/05/2015. Drawing no. PACKAGE TO DRG.NO.ARDE 08040002000000000PB,DTD 14/05/2015. Manufacturing Technology (i) Rubber Mixing Mill or Kneading M/C (ii) Extruder m/c (iii) Pulverizing m/c (iv) Roto Moulding Process / plastic injection moulding m/c (v) Grinder (vi) Drill Machine 9911358292.png Testing / Inspection Facility (vii) Other relevant Inspection & Testing facility	99	23 Number
6191700090 PACKAGING BOX ASSEMBLY FOR PINAKA ADM-I (DPICM) Description PACKAGING BOX ASSEMBLY FOR PINAKA ADM-I (DPICM) ROCKET ACCESSORIES TO ARDE DRG. No. 860302050000000DA Specification PACKAGING BOX ASSEMBLY FOR PINAKA ADM-I (DPICM) ROCKET ACCESSORIES TO ARDE DRG. No. 860302050000000DA Drawing no. 860302050000000DA Packaging_box_for_DPICM_drawing.PDF Manufacturing Technology As recommended by ARDE Manufacturing_technology_of_Packing_Box_for_Pinaka_ADM-DPICM.pdf Testing / Inspection Facility As recommended by ARDE	61	5000 Number
6191700090 PACKAGING BOX ASSEMBLY FOR PINAKA ADM-I (DPICM) Description PACKAGING BOX ASSEMBLY FOR PINAKA ADM-I (DPICM) ROCKET ACCESSORIES TO ARDE DRG. No. 860302050000000DA Specification PACKAGING BOX ASSEMBLY FOR PINAKA ADM-I (DPICM) ROCKET ACCESSORIES TO ARDE DRG. No. 860302050000000DA Drawing no. 860302050000000DA Packaging_box_for_DPICM_drawing.PDF Manufacturing Technology As recommended by ARDE Manufacturing_technology_of_Packing_Box_for_Pinaka_ADM-DPICM.pdf Testing / Inspection Facility As recommended by ARDE	61	5000 Number
SET OF INNER PACKING FITMENT FOR PACKING OF FUZE ASSEMBLY TO TBRL DRG.NO.9774 DET NO.2(PIECE HOUSING-II)3 NOS.IN A SETWITH PIECE PACKING TO TBRL DRG.NO.9774 DET.4 2 NOS IN A SETFOR MULTI MODE HAND GRENADE. (LF-9911358099) Physical Verification needed Description SET OF INNER PACKING FITMENT FOR PACKING OF FUZE ASSEMBLY TO TBRL DRG.NO.9774 DET NO.2(PIECE HOUSING-II)3 NOS.IN A SETWITH PIECE PACKING TO TBRL DRG.NO.9774 DET.4 2 NOS IN A SETFOR MULTI MODE HAND GRENADE. (LF-9911358099) Specification SET OF INNER PACKING FITMENT FOR PACKING OF FUZE ASSEMBLY TO TBRL DRG.NO.9774 DET NO.2(PIECE HOUSING-II)3 NOS.IN A SETWITH PIECE PACKING TO TBRL DRG.NO.9774 DET.4 2 NOS IN A SETFOR MULTI MODE HAND GRENADE. (LF-9911358099) Drawing no. Manufacturing Technology TO BE UPLOADED DUMMYY.pdf Testing / Inspection Facility TO BE UPLOADED	99	5671 Set
CAP TO DRG NO 9 0643 Description CAP TO DRG.NO.9-0643/9- -104/1,DC. 37511-A,DT-11.12.18. Specification CAP TO DRG.NO.9-0643/9- -104/1,DC. 37511-A,DT-11.12.18. Drawing no. Manufacturing Technology SUITABLE PRESS MACHINE,SUITABLE SURFACE TREATMENT FACILITY OR TIE-UP FOR THE SAME,SUITABLE FINISHING FACILITY CAP_DRG9.pdf Testing / Inspection Facility SUITABLE MEASURING FACILITY	63	744434 Number
POLYSTER TAPE FOR 84MM SMOKE 469C LF 2101776135 Description POLYSTER TAPE (PART NO.405006545,DRAWING NO.305127351) FOR BURSTER OF 84MM SMOKE-469C AMMN. (LF-2101776135) Specification POLYSTER TAPE (PART NO.405006545,DRAWING NO.305127351) FOR BURSTER OF 84MM SMOKE-469C AMMN. (LF-2101776135) Drawing no. Manufacturing Technology TO BE UPLOADED DUMMYY.pdf Testing / Inspection Facility TO BE UPLOADED	21	100587 Number
GLUE 51-K-10 BM AS PER TY 2513-001-00152081-93 Physical Verification needed Description GLUE 51-K-10 BM AS PER TY 2513-001-00152081-93 Specification GLUE 51-K-10 BM AS PER TY 2513-001-00152081-93 Glue_51-K_-_10_BM.pdf Drawing no. Manufacturing Technology GLUE 51-K-10 BM AS PER TY 2513-001-00152081-93 Glue_51-K_-_10_BM.pdf Testing / Inspection Facility GLUE 51-K-10 BM AS PER TY 2513-001-00152081-93	01	44 Kilogram
PRECOAT P-11 AS PER TU 38-303-04-06-90 Physical Verification needed Description PRECOAT P-11 AS PER TU 38-303-04-06-90 Specification PRECOAT P-11 AS PER TU 38-303-04-06-90 Precoat_P-11.pdf Drawing no. Manufacturing Technology PRECOAT P-11 AS PER TU 38-303-04-06-90 Precoat_P-11.pdf Testing / Inspection Facility PRECOAT P-11 AS PER TU 38-303-04-06-90	01	6 Kilogram
COMPOUND K-68 AS PER TU 38.103508-81 Physical Verification needed Description COMPOUND K-68 AS PER TU 38.103508-81 Specification COMPOUND K-68 AS PER TU 38.103508-81 Compound_K-68.pdf Drawing no. Manufacturing Technology COMPOUND K-68 AS PER TU 38.103508-81 Compound_K-68.pdf Testing / Inspection Facility COMPOUND K-68 AS PER TU 38.103508-81	01	76 Kilogram
SHELL W/DB 40MM L-70 HE/T UPGRADED (EMPTY) TO DESIG. REF 5073229 DC NO. 37033-A DT. 22-11-05. ALONG WITH BOTTOM SCREW TO DRG NO. 6171222 (LF: 9911358884) Physical Verification needed Description SHELL W/DB 40MM L-70 HE/T UPGRADED (EMPTY) TO DESIG. REF 5073229 DC NO. 37033-A DT. 22-11-05. ALONG WITH BOTTOM SCREW TO DRG NO. 6171222 (LF: 9911358884) (LF: 9911358884) Specification SHELL W/DB 40MM L-70 HE/T UPGRADED (EMPTY) TO DESIG. REF 5073229 DC NO. 37033-A DT. 22-11-05. ALONG WITH BOTTOM SCREW TO DRG NO. 6171222 (LF: 9911358884) (LF: 9911358884) Drawing no. Manufacturing Technology TO BE UPLOADED DUMMYY.pdf Testing / Inspection Facility TO BE UPLOADED	99	114105 Number
MMHG MK1 FILLED LF- 9911358911 Physical Verification needed Description MMHG MK1 FILLED AS PER TBRL DRG NO. TBRL/MMG-H/MK1/A00/R3 Specification MMHG MK1 FILLED AS PER TBRL DRG NO. TBRL/MMG-H/MK1/A00/R3 Drawing no. Manufacturing Technology To be uploaded DUMMYY.pdf Testing / Inspection Facility To be uploaded	99	320000 Number
6191700090 PACKAGING BOX ASSEMBLY FOR PINAKA ADM-I (DPICM) Description PACKAGING BOX ASSEMBLY FOR PINAKA ADM-I (DPICM) ROCKET ACCESSORIES TO ARDE DRG. No. 860302050000000DA Specification PACKAGING BOX ASSEMBLY FOR PINAKA ADM-I (DPICM) ROCKET ACCESSORIES TO ARDE DRG. No. 860302050000000DA Drawing no. 860302050000000DA Packaging_box_for_DPICM_drawing.PDF Manufacturing Technology As recommended by ARDE Manufacturing_technology_of_Packing_Box_for_Pinaka_ADM-DPICM.pdf Testing / Inspection Facility As recommended by ARDE	61	49 Number
6191700080 Metallic Breake Ring Large for EPRS Physical Verification needed Description METALLIC BREAKE RING (LARGE) FOR EPRS TO ARDE DRG. NO. 1905 01 03 00 00 004 00DA Specification METALLIC BREAKE RING (LARGE) FOR EPRS TO ARDE DRG. NO. 1905 01 03 00 00 004 00DA Drawing no. DRG. NO. 1905 01 03 00 00 004 00DA Drawing_Brake_Ring_(Large)_metallic.pdf Manufacturing Technology Lathe /CNC Machine, Punch Machine, Blank Cutting Machine, Zink and Cromate Plating Facility. mfg_facility_Metallic_Breake_Ring_Large_for_EPRS.pdf Testing / Inspection Facility Testing as per Specification	61	5000 Number
619170081 Metallic Breake Ring Big for EPRS Physical Verification needed Description METALLIC BREAKE RING (BIG) FOR EPRS TO ARDE DRG. NO. 1905 01 03 00 00 003 00DA. Specification METALLIC BREAKE RING (BIG) FOR EPRS TO ARDE DRG. NO. 1905 01 03 00 00 003 00DA. Drawing no. 1905 01 03 00 00 003 00DA. Brake_Ring_(BIG)_metallic.pdf Manufacturing Technology Lathe /CNC Machine, Punch Machine, Blank Cutting Machine, Zink and Cromate Plating Facility. mfg_facility_Metallic_Breake_Ring_Big_for_EPRS.pdf Testing / Inspection Facility Testing as per Specification	61	5000 Number
619170081 Metallic Breake Ring Big for EPRS Physical Verification needed Description METALLIC BREAKE RING (BIG) FOR EPRS TO ARDE DRG. NO. 1905 01 03 00 00 003 00DA. Specification METALLIC BREAKE RING (BIG) FOR EPRS TO ARDE DRG. NO. 1905 01 03 00 00 003 00DA. Drawing no. 1905 01 03 00 00 003 00DA. Brake_Ring_(BIG)_metallic.pdf Manufacturing Technology Lathe /CNC Machine, Punch Machine, Blank Cutting Machine, Zink and Cromate Plating Facility. mfg_facility_Metallic_Breake_Ring_Big_for_EPRS.pdf Testing / Inspection Facility Testing as per Specification	61	5000 Number
6191700080 Metallic Breake Ring Large for EPRS Physical Verification needed Description METALLIC BREAKE RING (LARGE) FOR EPRS TO ARDE DRG. NO. 1905 01 03 00 00 004 00DA Specification METALLIC BREAKE RING (LARGE) FOR EPRS TO ARDE DRG. NO. 1905 01 03 00 00 004 00DA Drawing no. DRG. NO. 1905 01 03 00 00 004 00DA Drawing_Brake_Ring_(Large)_metallic.pdf Manufacturing Technology Lathe /CNC Machine, Punch Machine, Blank Cutting Machine, Zink and Cromate Plating Facility. mfg_facility_Metallic_Breake_Ring_Large_for_EPRS.pdf Testing / Inspection Facility Testing as per Specification	61	5000 Number
619170081 Metallic Breake Ring Big for EPRS Physical Verification needed Description METALLIC BREAKE RING (BIG) FOR EPRS TO ARDE DRG. NO. 1905 01 03 00 00 003 00DA. Specification METALLIC BREAKE RING (BIG) FOR EPRS TO ARDE DRG. NO. 1905 01 03 00 00 003 00DA. Drawing no. 1905 01 03 00 00 003 00DA. Brake_Ring_(BIG)_metallic.pdf Manufacturing Technology Lathe /CNC Machine, Punch Machine, Blank Cutting Machine, Zink and Cromate Plating Facility. mfg_facility_Metallic_Breake_Ring_Big_for_EPRS.pdf Testing / Inspection Facility Testing as per Specification	61	5000 Number
6191700080 Metallic Breake Ring Large for EPRS Physical Verification needed Description METALLIC BREAKE RING (LARGE) FOR EPRS TO ARDE DRG. NO. 1905 01 03 00 00 004 00DA Specification METALLIC BREAKE RING (LARGE) FOR EPRS TO ARDE DRG. NO. 1905 01 03 00 00 004 00DA Drawing no. DRG. NO. 1905 01 03 00 00 004 00DA Drawing_Brake_Ring_(Large)_metallic.pdf Manufacturing Technology Lathe /CNC Machine, Punch Machine, Blank Cutting Machine, Zink and Cromate Plating Facility. mfg_facility_Metallic_Breake_Ring_Large_for_EPRS.pdf Testing / Inspection Facility Testing as per Specification	61	5000 Number
619170081 Metallic Breake Ring Big for EPRS Physical Verification needed Description METALLIC BREAKE RING (BIG) FOR EPRS TO ARDE DRG. NO. 1905 01 03 00 00 003 00DA. Specification METALLIC BREAKE RING (BIG) FOR EPRS TO ARDE DRG. NO. 1905 01 03 00 00 003 00DA. Drawing no. 1905 01 03 00 00 003 00DA. Brake_Ring_(BIG)_metallic.pdf Manufacturing Technology Lathe /CNC Machine, Punch Machine, Blank Cutting Machine, Zink and Cromate Plating Facility. mfg_facility_Metallic_Breake_Ring_Big_for_EPRS.pdf Testing / Inspection Facility Testing as per Specification	61	5000 Number
ELECTRONIC TIME FUZE FOR SHELL 1 55MM ILLG. NASCHEM. Description TIME FUZE M85P13T3 ELECTRONIC, FOR SHELL 1 55MM ILLG. NASCHEM. Specification TIME FUZE M85P13T3 ELECTRONIC, FOR SHELL 1 55MM ILLG. NASCHEM. Drawing no. Manufacturing Technology AS PER SPECIFICATION Electronic_Fuze_drg.pdf Electronic_Fuze_T3_spec.pdf Testing / Inspection Facility AS PER SPECIFICATION	63	100 Number
AMMN.CONTAINER BOX M 41A WOOD AND PACKING FITMENTS Description AMMN.CONTAINER BOX M 41A (WOOD) AND PACKING FITMENTS TO DRG.PT.NO.ISV 587 A, DC.37127-A DT.30.07.07. Specification AMMN.CONTAINER BOX M 41A (WOOD) AND PACKING FITMENTS TO DRG.PT.NO.ISV 587 A, DC.37127-A DT.30.07.07. Drawing no. Manufacturing Technology GENERAL PURPOSE CARPENTRY TOOLS,WOOD CUTTING FACILITY & PLANNER MACHINE,PRESSURE TREATMENT TANK/CHEMICAL TREATMENT FACILITY SUITABLE PAINTING FACILITY,HAND PRESS MACHINE BOX_M41_UNIT_LOAD_MOP.pdf Testing / Inspection Facility SUITABLE MEASUREMENT EQUIPMENT, TESTING FACILITY AS PER PRODUCT SPECIFICATION REQUIREMENT ETC.	14	4548 Number
CARTRIDGE CASE FOR 30MM GUN 2A42 Physical Verification needed Description CARTRIDGE CASE FOR 30MM GUN 2A42 TO DRG.NO.3-0105575,A4-T-84-0514 (4 SHEETS) DC NO.36579-A,DATED-3.8.99. Specification CARTRIDGE CASE FOR 30MM GUN 2A42 TO DRG.NO.3-0105575,A4-T-84-0514 (4 SHEETS) DC NO.36579-A,DATED-3.8.99. Drawing no. Manufacturing Technology Multiple Press of minimum 200 T load capacity for progressing drawing, Heat Treatment Facility for inter stage annealing, stress relieving and hardening, Multiple spindle CNC Lathe Machine/conventional lathe machine for various machining operation, Lapping machine for surface Polishing, In-house Electroplating facility/ MOU or Tie- up with outsourced facility. 30_cc_gun_mod_mfg.pdf Testing / Inspection Facility SUITABLE MEASURING FACILITY	65	50000 Number
PAPER WHITE FINE 51X76CMSX84 92 GSM LF 1415562115 Description PAPER WHITE FINE AMMN. 51 X 76CMS X 84-92 GSM TO SPECN:- JSS-9310-06:2016 ( REV NO.1). Specification PAPER WHITE FINE AMMN. 51 X 76CMS X 84-92 GSM TO SPECN:- JSS-9310-06:2016 ( REV NO.1). Drawing no. Manufacturing Technology uploaded soon dummy_pm.pdf Testing / Inspection Facility uploaded soon	14	5650 Number
SOCKET AS PER DRG NO TRD 2 1 3227 LF 9911358671 Description SOCKET AS PER DRAWING NUMBER TRD-2.1.3227 LF - 9911358671 Specification SOCKET AS PER DRAWING NUMBER TRD-2.1.3227 LF - 9911358671 Drawing no. Manufacturing Technology TO BE UPLOADED DUMMYY.pdf Testing / Inspection Facility TO BE UPLOADED	99	18803 Number
CARTRIDGE CASE EMPTY FOR ROUND 14.5 MM Description CARTRIDGE CASE EMPTY, DRG. NO. 04-749-130222-06.1E, DC-36925A DT. 14-10-2003 SPECN NO. 04-749-0021-0013 Specification CARTRIDGE CASE EMPTY, DRG. NO. 04-749-130222-06.1E, DC-36925A DT. 14-10-2003 SPECN NO. 04-749-0021-0013 Drawing no. Manufacturing Technology AS PER DRAWING drg.pdf Testing / Inspection Facility AS PER DRAWING	60	80000 Number
GUN POWDER (SMP) Description GUN POWDER SULPHUR FREE MEALED (SMP) TO SPECN. J.S.S.-1376 -05:2024 REVISION NO.5 DS CAT NO 1376 000 036 to 1376 000 047 NSN NO 13767203 Specification GUN POWDER SULPHUR FREE MEALED (SMP) TO SPECN. J.S.S.-1376 -05:2024 REVISION NO.5 DS CAT NO 1376 000 036 to 1376 000 047 NSN NO 13767203 Drawing no. Manufacturing Technology AS PER SPECIFICATION GUN_POWDER_SMP_specs.pdf Testing / Inspection Facility AS PER SPECIFICATION	10	3000 Kilogram
DOBECKOT 520 F Description DOBECKOT 520 F Specification DOBECKOT 520 F Drawing no. Manufacturing Technology DOBECKOT 520 F DOBECKOT.pdf Testing / Inspection Facility DOBECKOT 520 F	10	4000 Kilogram
PACKING FITMENT FOR CARTRIDGE SIGNAL 16MM Description PACKING FITMENT FOR CARTRIDGE SIGNAL 16MM TO DRAWING NO.CQA(A)/AMMN/3515, PART NO.ISV-2273 DC 37290 A DT.20-10-2011. Specification PACKING FITMENT FOR CARTRIDGE SIGNAL 16MM TO DRAWING NO.CQA(A)/AMMN/3515, PART NO.ISV-2273 DC 37290 A DT.20-10-2011. Drawing no. Manufacturing Technology AS PER DRAWING PACKING_FITMENT_drawing.pdf Testing / Inspection Facility AS PER DRAWING	65	6000 Set
AMMN.CONTAINER 39 A/L FOR SHELL 105 MM Description AMMN.CONTAINER 39 A/L TO DRG CIA/AMN/1565 PT NO ISV 414-A DC-36411A DT.23/04/1998 SPECN.NO. CQA(A) 2805 (h) DC-36145-A. Specification AMMN.CONTAINER 39 A/L TO DRG CIA/AMN/1565 PT NO ISV 414-A DC-36411A DT.23/04/1998 SPECN.NO. CQA(A) 2805 (h) DC-36145-A. Drawing no. Manufacturing Technology AS PER SPECIFICATION & DRAWING AMMN_CONTAINER_39_AL_specs.pdf AMMN_CONTAINER_drawing.pdf Testing / Inspection Facility AS PER SPECIFICATION & DRAWING	65	40000 Number
SET OF CIRCULAR CONNECTORS FOR IGNITER OF PINAKA M K- I(ENHANCED) Description SET OF CIRCULAR CONNECTORS FOR IGNITER OF PINAKA MK-I(ENHANCED) AS PER ITEM NOMENCLATURE 1) MG 01E 14S-2S ARCP 2) MG 06R 14S-2P GP SHT Specification SET OF CIRCULAR CONNECTORS FOR IGNITER OF PINAKA MK-I(ENHANCED) AS PER ITEM NOMENCLATURE 1) MG 01E 14S-2S ARCP 2) MG 06R 14S-2P GP SHT Drawing no. Manufacturing Technology As per specification set_of_circular_connectors_specs.pdf Testing / Inspection Facility As per specification	61	1000 Set
APPCP CARTONS FOR 7.62 M80-10 CARTG Description APPCP CARTONS FOR 7.62 M80-10 CARTG APPCP Cartons for Cartridges SA 7.62 M-80 As per Drg No.-V/PROV/0915 Specification APPCP CARTONS FOR 7.62 M80-10 CARTG APPCP Cartons for Cartridges SA 7.62 M-80 As per Drg No.-V/PROV/0915 Drawing no. Manufacturing Technology Moulding and Machining Drawing.pdf Testing / Inspection Facility As per Specification No. OFV/APPCP Cartons/Pkg. dated 26-10-2023	60	428400 Number
Gilding Metal Strip for 5.56mm Ammn. Description Gilding Metal Strip for 5.56mm Ammn. Cold Rolled to Specn. MIL-C-21768, 04.10.1962. Copper Alloy No. 210 (Gilding 95%). Size - 7.60mm (+/-) 0.127mm Wide X 0.165mm (+/-) 0.025mm Thick. Hardness Range : 80 to 100 VPN with 5 kg load (Quarter Hard). Coil Inner 50mm to 100mm Dia. Coil Outer 200mm to 300mm Dia (Approx) Note: OFV Hardness Range Reqt. 90-95 VPN Specification Gilding Metal Strip for 5.56mm Ammn. Cold Rolled to Specn. MIL-C-21768, 04.10.1962. Copper Alloy No. 210 (Gilding 95%). Size - 7.60mm (+/-) 0.127mm Wide X 0.165mm (+/-) 0.025mm Thick. Hardness Range : 80 to 100 VPN with 5 kg load (Quarter Hard). Coil Inner 50mm to 100mm Dia. Coil Outer 200mm to 300mm Dia (Approx) Note: OFV Hardness Range Reqt. 90-95 VPN copper_ally_sheet_and_strip_MIL-C-21768.pdf Drawing no. Not Applicable copper_ally_sheet_and_strip_MIL-C-21768.pdf Manufacturing Technology Brass Foundry Rolling of Sheets copper_ally_sheet_and_strip_MIL-C-21768.pdf Testing / Inspection Facility Spectroscopy Vernier, Micrometer & Dial Indicator Vickers Hardness Tester Microscope for Grain Size Measurement	60	335 Kilogram
GM Strip for 7.62 TCR Base Closure Description GM Strip for 7.62 TCR Base Closure Cold Rolled Hard to Specn. MIL-C-21768, 04.10.1962. Copper Alloy No. 210 (Gilding 95%). Size - 9.54mm (+/-) 0.127mm Wide X 0.165mm (+/-) 0.025mm Thick. Approx Hardness Range 80 to 100 VPN with 5 kg load (Quarter Hard). Coil Inner Dia 50mm to 100mm Approx. Coil Outer Dia 250mm to 350mm Approx. Specification GM Strip for 7.62 TCR Base Closure Cold Rolled Hard to Specn. MIL-C-21768, 04.10.1962. Copper Alloy No. 210 (Gilding 95%). Size - 9.54mm (+/-) 0.127mm Wide X 0.165mm (+/-) 0.025mm Thick. Approx Hardness Range 80 to 100 VPN with 5 kg load (Quarter Hard). Coil Inner Dia 50mm to 100mm Approx. Coil Outer Dia 250mm to 350mm Approx. Drawing no. Not Applicable Manufacturing Technology Brass Foundry Rolling of Sheets copper_ally_sheet_and_strip_MIL-C-21768.pdf Testing / Inspection Facility Spectroscopy Vernier, Micrometer & Dial Indicator Vickers Hardness Tester Microscope for Grain Size Measurement	60	1350 Kilogram
GM Cup for 7.62 mm Ball Bullet Description GM Cup for 7.62mm Ball Bullet 7.62mm Bullet NATO BALL M-80. To Specn. MIL-C-3383 B(AR) Drg. No. V/PROD/0002-D . ALT. No. 844. 17-09-1994. Strip Copper Alloy No. 220. Specn. IS 2768-1980 (I Rev.) Reaffirmed 2021 Specification GM Cup for 7.62mm Ball Bullet 7.62mm Bullet NATO BALL M-80. To Specn. MIL-C-3383 B(AR) Drg. No. V/PROD/0002-D . ALT. No. 844. 17-09-1994. Strip Copper Alloy No. 220. Specn. IS 2768-1980 (I Rev.) Reaffirmed 2021 GM_cup_bullet_jacket_MIL-C-3383.pdf IS_2768-1982_rev-I_Reaffirmed_2021_COPPER_ALLOY_STRIP_FOR_.pdf Drawing no. V/PROD/0002-D 762mm_GM_Cup_V-PROD-0002_D.pdf Manufacturing Technology Brass Foundry Rolling of Sheets Press for Blanking & Cupping Annealing Furnace Spectroscopy GM_cup_bullet_jacket_MIL-C-3383.pdf IS_2768-1982_rev-I_Reaffirmed_2021_COPPER_ALLOY_STRIP_FOR_.pdf Testing / Inspection Facility Vernier, Micrometer & Dial Indicator Vickers Hardness Tester Microscope for Grain Size Measurement [removed]void(0);	60	7.845 Metric tonne(1000kg)
GM Cup for 7.62 mm Tracer Bullet Description GM Cup for 7.62mm Tracer Bullet To Specn: - MIL-C-3383 B(AR) Strip Copper Alloy 220 IS-2768-1982 (Rev I) Reaffirmed 2021 Drg. No. V/PROD/0018-C Specification GM Cup for 7.62mm Tracer Bullet To Specn: - MIL-C-3383 B(AR) Strip Copper Alloy 220 IS-2768-1982 (Rev I) Reaffirmed 2021 Drg. No. V/PROD/0018-C GM_cup_bullet_jacket_MIL-C-3383.pdf IS_2768-1982_rev-I_Reaffirmed_2021_COPPER_ALLOY_STRIP_FOR_.pdf Drawing no. V/PROD/0018-C V-PROD-0018C.pdf Manufacturing Technology Brass Foundry Rolling of Sheets Press for Blanking & Cupping Annealing Spectroscopy GM_cup_bullet_jacket_MIL-C-3383.pdf IS_2768-1982_rev-I_Reaffirmed_2021_COPPER_ALLOY_STRIP_FOR_.pdf Testing / Inspection Facility Vernier, Micrometer & Dial Indicator Hardness Tester Microscope for Grain Size	60	2925 Kilogram
GM Cup for AK-47 Bullet Description GM Cup for AK-47 Bullet Drg. No. VA7/PROV/0008A Spcn : IS 2768-1982 (First Revision) Reaffirmed 2021 Specification GM Cup for AK-47 Bullet Drg. No. VA7/PROV/0008A Spcn : IS 2768-1982 (First Revision) Reaffirmed 2021 IS_2768-1982_rev-I_Reaffirmed_2021_COPPER_ALLOY_STRIP_FOR_.pdf Drawing no. VA7/PROV/0008A AK-47_GM_Cup_VA7-PROV-0008_A.pdf Manufacturing Technology Brass Foundry Rolling of Sheets Press for Blanking & Cupping Annealing Furnance IS_2768-1982_rev-I_Reaffirmed_2021_COPPER_ALLOY_STRIP_FOR_.pdf Testing / Inspection Facility Spectroscopy Vernier, Micrometer & Dial Indicator Vickers Hardness Tester Microscope for Grain Size Measurement	60	8.94 Metric tonne(1000kg)
GM Cup for 5.56mm Ball Bullet Description GM Cup for 5.56mm Ball Bullet as per Drg. No. AFK/CUP/34 and to Specn. IS : 2768-1982 (First Revision) Reaffirmed 2021 Specification GM Cup for 5.56mm Ball Bullet as per Drg. No. AFK/CUP/34 and to Specn. IS : 2768-1982 (First Revision) Reaffirmed 2021 IS_2768-1982_rev-I_Reaffirmed_2021_COPPER_ALLOY_STRIP_FOR_.pdf Drawing no. AFK/CUP/34 556_Ball_Cup_Ammn_DRAWINGS_AFK-CUP-34.pdf Manufacturing Technology Brass Foundry Rolling of Sheets Press for Blanking & Cupping Annealing Furnace IS_2768-1982_rev-I_Reaffirmed_2021_COPPER_ALLOY_STRIP_FOR_.pdf Testing / Inspection Facility Spectroscopy Vernier, Micrometer & Dial Indicator Vickers Hardness Tester Microscope for Grain Size Measurement	60	2560 Kilogram
PAPER BOARD CORRUGATED 2 POINT 5 MM THICK LF 1411817752 Description PAPER AND BOARD CORRUGATED AMMN. DOUBLE FACED, FINE FLUTE, TO SPECN:- JSS-8135-08:2019 (REVISION NO.-5) TO SIZE 787.4 mm X 558.8 mm X 2.5 MM THICK. Specification PAPER AND BOARD CORRUGATED AMMN. DOUBLE FACED, FINE FLUTE, TO SPECN:- JSS-8135-08:2019 (REVISION NO.-5) TO SIZE 787.4 mm X 558.8 mm X 2.5 MM THICK. Drawing no. Manufacturing Technology uploaded soon file_will_be_uploaded_soon.png Testing / Inspection Facility uploaded soon	14	4026 Number
HTPB Description H.T.P.B. ( HYDROXY TERMINATED POLY BUTADIENE ) SPECIFICATION :-HEMRL/TRIM/PROP/RM/4.(REVISED).DT OF REVISION;09/01/2013. Specification H.T.P.B. ( HYDROXY TERMINATED POLY BUTADIENE ) SPECIFICATION :-HEMRL/TRIM/PROP/RM/4.(REVISED).DT OF REVISION;09/01/2013. SPEC_HTPB.pdf Drawing no. Manufacturing Technology MSME 1001611007_HEMRL-TRIM-PROP-RM-4.PDF Testing / Inspection Facility H.T.P.B. ( HYDROXY TERMINATED POLY BUTADIENE ) SPECIFICATION :-HEMRL/TRIM/PROP/RM/4.(REVISED).DT OF REVISION;09/01/2013.	10	415 Kilogram
COVER PART NO 6429713 LF 9911358447 Description COVER PART NO.6429713 TO OEM DRG.NO.304061235/TRD.DRG.NO. 1.2.2758 Specification COVER PART NO.6429713 TO OEM DRG.NO.304061235/TRD.DRG.NO. 1.2.2758 Drawing no. COVER PART NO.6429713 TO OEM DRG.NO.304061235/TRD.DRG.NO. 1.2.2758 Manufacturing Technology attached 9911358447.png Testing / Inspection Facility attached	99	46356 Number
Brass Cup for 12.7 SRCG Ammn Case Description Brass Cup for 12.7 SRCG Ammn Case As per OFV Drawing No. V/SRCG/PROV/0002 Specification Brass Cup for 12.7 SRCG Ammn Case As per OFV Drawing No. V/SRCG/PROV/0002 MIL-C-10375_C_CUPS _CASE_COPPER_ALLOY_(1).pdf Drawing no. V/SRCG/PROV/0002 V-SRCG-PROV-0002.pdf Manufacturing Technology Brass Foundry Rolling of Sheets Press for Blanking & Cupping Annealing Furnance Spectroscopy MIL-A-2550B.PDF Testing / Inspection Facility Vernier, Micrometer & Dial Indicator Vickers Hardness Tester Microscope for Grain Size Measurement	60	1020 Kilogram
Brass Strip for 27mm X 0.9mm Thick Description Brass Strip for 27mm X 0.9mm Thick Size: 27mm (+/-) 0.13mm Wide X 0.90mm (+/-) 0.02mm Thick To Specn. JSS 9535-02 : 2019 (Revision No. 5) Hardness: 70 - 95 V. P. N. at 10 Kg. Load To Drg. No. V12.7/PROD/052 Specification Brass Strip for 27mm X 0.9mm Thick Size: 27mm (+/-) 0.13mm Wide X 0.90mm (+/-) 0.02mm Thick To Specn. JSS 9535-02 : 2019 (Revision No. 5) Hardness: 70 - 95 V. P. N. at 10 Kg. Load To Drg. No. V12.7/PROD/052 JSS_9535-02-2019_(Fifth_Revision)_Cartridge_Brass_For_Ammunition_Components.pdf Drawing no. V12.7/PROD/052 V127-PROD-052_Brass_Strip_for_127mm.pdf Manufacturing Technology Brass Foundry Rolling of Sheets Press for Blanking & Cupping Annealing Furnace JSS_9535-02-2019_(Fifth_Revision)_Cartridge_Brass_For_Ammunition_Components.pdf Testing / Inspection Facility Spectroscopy Vernier, Micrometer & Dial Indicator Vickers Hardness Tester Microscope for Grain Size Measurement	60	310 Kilogram
Brass Strip 15 mm For 5.56 mm Primer Cup Description Brass Strip 15 mm For 5.56 mm Primer Cup Size: 15 mm (+/-) 0.13 mm Wide X 0.69 mm (+/-) 0.013 mm Thick To Specification:- JSS: 9535-02-2019 (Revision No. 5) To Drawing No. :- V/PROD/0039-H Specification Brass Strip 15 mm For 5.56 mm Primer Cup Size: 15 mm (+/-) 0.13 mm Wide X 0.69 mm (+/-) 0.013 mm Thick To Specification:- JSS: 9535-02-2019 (Revision No. 5) To Drawing No. :- V/PROD/0039-H JSS_9535-02-2019_(Fifth_Revision)_Cartridge_Brass_For_Ammunition_Components.pdf Drawing no. V/PROD/0039-H Brass_Strip_15_16mm_(V-PROD-0039H).pdf Manufacturing Technology Brass Foundry & Rolling JSS_9535-02-2019_(Fifth_Revision)_Cartridge_Brass_For_Ammunition_Components.pdf Testing / Inspection Facility Spectroscopy & Micrometer, Vernier	60	2500 Kilogram
Brass Strip 11 mm For 5.56 mm Anvil Description Brass Strip 11 mm For 5.56 mm Anvil Size: 11 mm (+/-) 0.13 mm Wide X 0.97 mm (+/-) 0.025 mm Thick To Specification:- JSS: 9535-02-2019 (Revision No. 5) To Drawing No. :- V/PROD/0038H Specification Brass Strip 11 mm For 5.56 mm Anvil Size: 11 mm (+/-) 0.13 mm Wide X 0.97 mm (+/-) 0.025 mm Thick To Specification:- JSS: 9535-02-2019 (Revision No. 5) To Drawing No. :- V/PROD/0038H JSS_9535-02-2019_(Fifth_Revision)_Cartridge_Brass_For_Ammunition_Components.pdf Drawing no. V/PROD/0038H Brass_Strip_11_12mm_(V-PROD-0038H).pdf Manufacturing Technology Brass Foundry & Rolling JSS_9535-02-2019_(Fifth_Revision)_Cartridge_Brass_For_Ammunition_Components.pdf Testing / Inspection Facility Brass Foundry & Rolling	60	2500 Kilogram
Brass Cup for 5.56 Case Description Brass Cup for 5.56 Case (For 2 Draw Process) To Drawing No.:- V5/PROD/0059-D for 5.56mm Ammunition To Specification : - JSS : 9535-02-2019 (Revision No. 5) Specification Brass Cup for 5.56 Case (For 2 Draw Process) To Drawing No.:- V5/PROD/0059-D for 5.56mm Ammunition To Specification : - JSS : 9535-02-2019 (Revision No. 5) JSS_9535-02-2019_(Fifth_Revision)_Cartridge_Brass_For_Ammunition_Components.pdf Drawing no. V5/PROD/0059-D 556_Brass_Cup.pdf Manufacturing Technology Brass Foundry JSS_9535-02-2019_(Fifth_Revision)_Cartridge_Brass_For_Ammunition_Components.pdf Testing / Inspection Facility Spectroscopy	60	10.94 Metric tonne(1000kg)
