SPECN.NO.: IS : 3255-1979 EXCEPT THAT :- i) In appearance shade finish and in other respect not defined in this Specn. the material shall conform to the sealed pattern held in the custody of the Controller, CQAT&C, Kanpur.
ii) There shall be no presence of starch.
iii) Loss of scouring mild method is to be followed in lieu
of severe Method and shall not exceed 2%.
iv) Sampling plan & criteria for conformity and Packing &
Marking :- as per CQAT&C/QAI/TC-8/11(b).
Specification
SPECN.NO.: IS : 3255-1979 EXCEPT THAT :- i) In appearance shade finish and in other respect not defined in this Specn. the material shall conform to the sealed pattern held in the custody of the Controller, CQAT&C, Kanpur.
ii) There shall be no presence of starch.
iii) Loss of scouring mild method is to be followed in lieu
of severe Method and shall not exceed 2%.
iv) Sampling plan & criteria for conformity and Packing &
Marking :- as per CQAT&C/QAI/TC-8/11(b).
No. PROV/S/2599/TC-11/2009/01, Except That Clause No. 6.1 & 6.2 Which shall be suitable yarn count may be used in warp & weft in 3/1 twill weave to meet the functional & other constructional parameter along with feel & Finish & Clause no.16.1 which shall be as per schedule No.CQA(T&C)/P&M/35(d), except that the fabric shall be supplied in roll form only.
Specification
No. PROV/S/2599/TC-11/2009/01, Except That Clause No. 6.1 & 6.2 Which shall be suitable yarn count may be used in warp & weft in 3/1 twill weave to meet the functional & other constructional parameter along with feel & Finish & Clause no.16.1 which shall be as per schedule No.CQA(T&C)/P&M/35(d), except that the fabric shall be supplied in roll form only.
Drawing no.
Manufacturing Technology
Testing / Inspection Facility
21
38106
Metre
18483
3183000870
Small Arms Factory
The General Manager,
Kanpur
Kanpur
Kanpur, Uttar Pradesh
208009
NON FERROUS MATERIAL - ALUMINIUM.-TITANIUM- BORON MASTER ALLOY ROD 9.5 MM DIA (COIL FORM).
ITEM CODE : 0620173002 (VIRGIN MATERIAL)
Specification
AL.-TI. BORON MASTER ALLOY ROD 9.5 MM DIA (COIL FORM) IN RUNNING LENGTH.CHEMICAL COMPOSITION AS PER DESIGNATED "AA" HARDENER H 2252 WITH TITANIUM 4.5% TO 5.5%,BORON 0.8% TO 1.2%,SI-0.20% MAX,FE-0.30% MAX,V-0.20% MAX OTHER TRACE ELEMENTS i.e. Zn, Mg SHOULD NOT BE EXCEED 0.10% IN TOTAL.TOTAL IMPURITIES NOT TO EXCEED 0.80% REMINDER ALUMINIUM. SIZE :- 9.5 +/- 0.5MM DIA ROD HAVING COIL INNER DIA 370 +/- 10 MM, COIL WIDTH 300 +/- 10 MM DIA.
Drawing no.
Manufacturing Technology
Testing / Inspection Facility
06
AS PER REQUIREMENT
Kilogram
18485
OPF/ADVANCE VR/EOI/JANUARY-19/TAPE-01
Ordnance Parachute Factory
The General Manager,
Kanpur
Kanpur
Kanpur, Uttar Pradesh
208004
AS PER PARTICULARS GIVEN IN SHEET NO.102 OF DRAWING NO. ADRDE/1164/A-7(a)
WIDTH - 25.4 MM,
THICKNESS - 2.35 MM (MAX)
MASS/METER - 36.5 GM (MAX.)
NO. OF ENDS - 316 +2 (GOLDEN THREAD AT CENTRE)
PICKS/CM - 10 INCLUDING BOTH LAYERS
B.S. - 1850 KG (MIN.)
WEAVE - TUBULAR PLAIN
Specification
AS PER PARTICULARS GIVEN IN SHEET NO.102 OF DRAWING NO. ADRDE/1164/A-7(a)
WIDTH - 25.4 MM,
THICKNESS - 2.35 MM (MAX)
MASS/METER - 36.5 GM (MAX.)
NO. OF ENDS - 316 +2 (GOLDEN THREAD AT CENTRE)
PICKS/CM - 10 INCLUDING BOTH LAYERS
B.S. - 1850 KG (MIN.)
WEAVE - TUBULAR PLAIN
Except that in apperance finish and all other respects not
defined in this specn., the material shall conform to the
sealed pattern held in the custody of controller CQAT&C
Kanpur.There shall be no presence of starch. Scouring loss
Mild method is to be followed in lieu of severe method and shall not exceed 2% picks/cm (-1) tolerance to be permittd. In addition the firm shall get their name or trade mark woven/stamped alongwith seldvedges at a interval of one meter on either side of the tape.(2)Sampling plan and criteria of conformtty:as per QAI NO.CQAT&C/TC-8/11(b).(3)Packing Marking:As per relevant clause of specn.
Specification
Except that in apperance finish and all other respects not
defined in this specn., the material shall conform to the
sealed pattern held in the custody of controller CQAT&C
Kanpur.There shall be no presence of starch. Scouring loss
Mild method is to be followed in lieu of severe method and shall not exceed 2% picks/cm (-1) tolerance to be permittd. In addition the firm shall get their name or trade mark woven/stamped alongwith seldvedges at a interval of one meter on either side of the tape.(2)Sampling plan and criteria of conformtty:as per QAI NO.CQAT&C/TC-8/11(b).(3)Packing Marking:As per relevant clause of specn.
1-LENGTH PER ROLL(MIN) --100M ---IS:1954
2-WIDTH IN MM 28 + - 0.5 ---IS:1954
3-THICKNESS IN MM AT 200GM/CM^2 PRESSURE(MAX)--1.0--IS:7702
4-MASS,gm,MAX --17gm ---IS:4727
5-BREAKING LOAD "N" MIN. --7500 ---IS:1969
6-TOTAL NO.OF ENDS(FULL WIDTH) --135 ----IS:1963
7-PICKS/CM --14 -----IS:1963
8-LINEAR DENSITY OF YARN,TEX WARP ---93.3
WEFT ---23.3 X 2
9-WEAVE PLAIN ----VISUAL (2 PICKS/SHED)
Specification
1-LENGTH PER ROLL(MIN) --100M ---IS:1954
2-WIDTH IN MM 28 + - 0.5 ---IS:1954
3-THICKNESS IN MM AT 200GM/CM^2 PRESSURE(MAX)--1.0--IS:7702
4-MASS,gm,MAX --17gm ---IS:4727
5-BREAKING LOAD "N" MIN. --7500 ---IS:1969
6-TOTAL NO.OF ENDS(FULL WIDTH) --135 ----IS:1963
7-PICKS/CM --14 -----IS:1963
8-LINEAR DENSITY OF YARN,TEX WARP ---93.3
WEFT ---23.3 X 2
9-WEAVE PLAIN ----VISUAL (2 PICKS/SHED)
SPECN NO. AS PER PARTICULARS. 1.WIDTH (MM) 26+-1
2.THICKNESS AT 200 gms/SQ.CM PRESSURE,MM MAX 3.25
3.MASS/METERS,(gm) MAX 47
4-ENDS IN FULL WIDTH SUGGESTED 130
5.PICKS/CM SUGGESTED 12(INCLUDING BOTH LAYERS)
6.DENIER OF WARP/WEFT NOMINAL 840X3 /210X5
7.BREAKING STRENGTH kgf,min.N) 2000
8.TPM IN WARP/WEFT 100-200/100-200
Specification
SPECN NO. AS PER PARTICULARS. 1.WIDTH (MM) 26+-1
2.THICKNESS AT 200 gms/SQ.CM PRESSURE,MM MAX 3.25
3.MASS/METERS,(gm) MAX 47
4-ENDS IN FULL WIDTH SUGGESTED 130
5.PICKS/CM SUGGESTED 12(INCLUDING BOTH LAYERS)
6.DENIER OF WARP/WEFT NOMINAL 840X3 /210X5
7.BREAKING STRENGTH kgf,min.N) 2000
8.TPM IN WARP/WEFT 100-200/100-200
SPECN-ADRDE/SPECN/2002/57 THE TAPE SHALL BE IN CONTINUOUS LENGTH OF 105 M (EXCLUTING SAMPLING ) WITHOUT ANY FLAG OTHERWISE THAT ROLL WILL BE TREATED AS SHORT LENGTH.
Specification
SPECN-ADRDE/SPECN/2002/57 THE TAPE SHALL BE IN CONTINUOUS LENGTH OF 105 M (EXCLUTING SAMPLING ) WITHOUT ANY FLAG OTHERWISE THAT ROLL WILL BE TREATED AS SHORT LENGTH.
