COLD ROLLED STEEL STRIP 2.2(+/-0.1) MM THICK X 90(+/-2) MM WIDE X 1000 MM LONG TO SPECN IS:1570-79 GRADE:40 C8, TO BE SUPPLIED IN RUST FREE & BRIGHT ANNEALED CONDITION IN POLYTHENE PACKS.
Specification
COLD ROLLED STEEL STRIP 2.2(+/-0.1) MM THICK X 90(+/-2) MM WIDE X 1000 MM LONG TO SPECN IS:1570-79 GRADE:40 C8, TO BE SUPPLIED IN RUST FREE & BRIGHT ANNEALED CONDITION IN POLYTHENE PACKS.
FULLY ASSEMBLED ESR COPPER MOULD 750 MM DIA WITH WATER COOLING SYSTEM AS PER MSF DRAWING NO.ESR/1000/19(R2) AND ESR/1000/19/1(R1) (HOLES FOR LEVEL SENSORS ARE NOT REQUIRED)
Specification
FULLY ASSEMBLED ESR COPPER MOULD 750 MM DIA WITH WATER COOLING SYSTEM AS PER MSF DRAWING NO.ESR/1000/19(R2) AND ESR/1000/19/1(R1) (HOLES FOR LEVEL SENSORS ARE NOT REQUIRED)
CERAMIC FIBRE MONOLITHIC MODULE,CLASSIFICATION TEMP:1425 DEGCEN. UNCOMPRESSED DENSITY:240Kg/Cu Mtr,SIZE: 300 X 300 X 300 mm WITH ANCHORING AS PER DETAILED SPECIFICATION.
Specification
CERAMIC FIBRE MONOLITHIC MODULE,CLASSIFICATION TEMP:1425 DEGCEN. UNCOMPRESSED DENSITY:240Kg/Cu Mtr,SIZE: 300 X 300 X 300 mm WITH ANCHORING AS PER DETAILED SPECIFICATION.
Drawing no.
Manufacturing Technology
Testing / Inspection Facility
20
1400
Number
35228
ORDFYS/MSF/CPP/VENDOR REGISTRATION/18(1)/PV-1
Metal and Steel Factory
The General Manager,
Ishapore
Ishapore
Ishapur, West Bengal
743144
ZINC BASE ALLOY FOR DIE CASTING TO SPECIFICATION IS:713-1981 GRADE Zn. Al.4 IN NOTCHED INGOT FORM NORMALLY HAVING WEIGHT 05 TO 20 Kg.{ NOTE: FIRM's T.C.FROM NABL ACCREDITED LAB/GOVT .RECOGNISED LAB AS PER SPECN.(SPECIALLY FOR THALLIUM & INDIUM % ) MUST BE ATTACHED WHILE SUPPLYING MATERIAL.}
Specification
ZINC BASE ALLOY FOR DIE CASTING TO SPECIFICATION IS:713-1981 GRADE Zn. Al.4 IN NOTCHED INGOT FORM NORMALLY HAVING WEIGHT 05 TO 20 Kg.{ NOTE: FIRM's T.C.FROM NABL ACCREDITED LAB/GOVT .RECOGNISED LAB AS PER SPECN.(SPECIALLY FOR THALLIUM & INDIUM % ) MUST BE ATTACHED WHILE SUPPLYING MATERIAL.}
"GRAPHITE ELECTRODE SIZE:NOMINAL DIA-350MM(14"" APPRX) X LONG-1800MM WITH 6.35MM PITCH(1/4""APPROX.)THREADED TAPERED & NIPPLE AS PER IS : 9050-1979 NOTE:-20% EXTRA NOS. OF NIPPLES TO BE SUPPLIED ALONGWITH WHOLE LOT.
"
Specification
"GRAPHITE ELECTRODE SIZE:NOMINAL DIA-350MM(14"" APPRX) X LONG-1800MM WITH 6.35MM PITCH(1/4""APPROX.)THREADED TAPERED & NIPPLE AS PER IS : 9050-1979 NOTE:-20% EXTRA NOS. OF NIPPLES TO BE SUPPLIED ALONGWITH WHOLE LOT.
"
LIME STONE (ESRGRADE) TO SPECIFICATION IS -4140/1978,REAFFIRMED -2000 GRADE - 1: LUMP SIZE 40 MM TO 60 MM . THE LIME STONE SHOULD BE FREE FROM MICACIOUS MATTER AND MAXIMUM 05% UNDER SIZE MATERIAL IS ALLOWED.
Specification
LIME STONE (ESRGRADE) TO SPECIFICATION IS -4140/1978,REAFFIRMED -2000 GRADE - 1: LUMP SIZE 40 MM TO 60 MM . THE LIME STONE SHOULD BE FREE FROM MICACIOUS MATTER AND MAXIMUM 05% UNDER SIZE MATERIAL IS ALLOWED.
DE-PLATING & ZINC PLATING FOLLOWED BY CHROMATISING ON 30 MM CARTRIDGE CASE AS PER DRG.NO.NCC-416 R1. OTHER DETAILS FOR WORKS AND INSPECTION, SCOPE OF WORK (ENCLOSED) SHOULD BE FOLLOWED.
Specification
DE-PLATING & ZINC PLATING FOLLOWED BY CHROMATISING ON 30 MM CARTRIDGE CASE AS PER DRG.NO.NCC-416 R1. OTHER DETAILS FOR WORKS AND INSPECTION, SCOPE OF WORK (ENCLOSED) SHOULD BE FOLLOWED.
SLIDE GATE MECHANISM CONSISTING OF (a) ADOPTER PLATE FOR MODEL 3150 (b) FLOCON MODEL 3150 STD. MECHANISM FOR BELL CRANK SYSTEM INCLUDING MOUNTING PLATE,CONNECTION ROD BUT WITHOUT SPRINGS/THERMO DYNAMIC ELEMENTS.
Specification
SLIDE GATE MECHANISM CONSISTING OF (a) ADOPTER PLATE FOR MODEL 3150 (b) FLOCON MODEL 3150 STD. MECHANISM FOR BELL CRANK SYSTEM INCLUDING MOUNTING PLATE,CONNECTION ROD BUT WITHOUT SPRINGS/THERMO DYNAMIC ELEMENTS.
AS PER PARTICULARS GIVEN IN SHEET NO.102 OF DRAWING NO. ADRDE/1164/A-7(a)
WIDTH - 25.4 MM,
THICKNESS - 2.35 MM (MAX)
MASS/METER - 36.5 GM (MAX.)
NO. OF ENDS - 316 +2 (GOLDEN THREAD AT CENTRE)
PICKS/CM - 10 INCLUDING BOTH LAYERS
B.S. - 1850 KG (MIN.)
WEAVE - TUBULAR PLAIN
Specification
AS PER PARTICULARS GIVEN IN SHEET NO.102 OF DRAWING NO. ADRDE/1164/A-7(a)
WIDTH - 25.4 MM,
THICKNESS - 2.35 MM (MAX)
MASS/METER - 36.5 GM (MAX.)
NO. OF ENDS - 316 +2 (GOLDEN THREAD AT CENTRE)
PICKS/CM - 10 INCLUDING BOTH LAYERS
B.S. - 1850 KG (MIN.)
WEAVE - TUBULAR PLAIN
Except that in apperance finish and all other respects not
defined in this specn., the material shall conform to the
sealed pattern held in the custody of controller CQAT&C
Kanpur.There shall be no presence of starch. Scouring loss
Mild method is to be followed in lieu of severe method and shall not exceed 2% picks/cm (-1) tolerance to be permittd. In addition the firm shall get their name or trade mark woven/stamped alongwith seldvedges at a interval of one meter on either side of the tape.(2)Sampling plan and criteria of conformtty:as per QAI NO.CQAT&C/TC-8/11(b).(3)Packing Marking:As per relevant clause of specn.
Specification
Except that in apperance finish and all other respects not
defined in this specn., the material shall conform to the
sealed pattern held in the custody of controller CQAT&C
Kanpur.There shall be no presence of starch. Scouring loss
Mild method is to be followed in lieu of severe method and shall not exceed 2% picks/cm (-1) tolerance to be permittd. In addition the firm shall get their name or trade mark woven/stamped alongwith seldvedges at a interval of one meter on either side of the tape.(2)Sampling plan and criteria of conformtty:as per QAI NO.CQAT&C/TC-8/11(b).(3)Packing Marking:As per relevant clause of specn.
1-LENGTH PER ROLL(MIN) --100M ---IS:1954
2-WIDTH IN MM 28 + - 0.5 ---IS:1954
3-THICKNESS IN MM AT 200GM/CM^2 PRESSURE(MAX)--1.0--IS:7702
4-MASS,gm,MAX --17gm ---IS:4727
5-BREAKING LOAD "N" MIN. --7500 ---IS:1969
6-TOTAL NO.OF ENDS(FULL WIDTH) --135 ----IS:1963
7-PICKS/CM --14 -----IS:1963
8-LINEAR DENSITY OF YARN,TEX WARP ---93.3
WEFT ---23.3 X 2
9-WEAVE PLAIN ----VISUAL (2 PICKS/SHED)
Specification
1-LENGTH PER ROLL(MIN) --100M ---IS:1954
2-WIDTH IN MM 28 + - 0.5 ---IS:1954
3-THICKNESS IN MM AT 200GM/CM^2 PRESSURE(MAX)--1.0--IS:7702
4-MASS,gm,MAX --17gm ---IS:4727
5-BREAKING LOAD "N" MIN. --7500 ---IS:1969
6-TOTAL NO.OF ENDS(FULL WIDTH) --135 ----IS:1963
7-PICKS/CM --14 -----IS:1963
8-LINEAR DENSITY OF YARN,TEX WARP ---93.3
WEFT ---23.3 X 2
9-WEAVE PLAIN ----VISUAL (2 PICKS/SHED)
SPECN NO. AS PER PARTICULARS. 1.WIDTH (MM) 26+-1
2.THICKNESS AT 200 gms/SQ.CM PRESSURE,MM MAX 3.25
3.MASS/METERS,(gm) MAX 47
4-ENDS IN FULL WIDTH SUGGESTED 130
5.PICKS/CM SUGGESTED 12(INCLUDING BOTH LAYERS)
6.DENIER OF WARP/WEFT NOMINAL 840X3 /210X5
7.BREAKING STRENGTH kgf,min.N) 2000
8.TPM IN WARP/WEFT 100-200/100-200
Specification
SPECN NO. AS PER PARTICULARS. 1.WIDTH (MM) 26+-1
2.THICKNESS AT 200 gms/SQ.CM PRESSURE,MM MAX 3.25
3.MASS/METERS,(gm) MAX 47
4-ENDS IN FULL WIDTH SUGGESTED 130
5.PICKS/CM SUGGESTED 12(INCLUDING BOTH LAYERS)
6.DENIER OF WARP/WEFT NOMINAL 840X3 /210X5
7.BREAKING STRENGTH kgf,min.N) 2000
8.TPM IN WARP/WEFT 100-200/100-200
SPECN-ADRDE/SPECN/2002/57 THE TAPE SHALL BE IN CONTINUOUS LENGTH OF 105 M (EXCLUTING SAMPLING ) WITHOUT ANY FLAG OTHERWISE THAT ROLL WILL BE TREATED AS SHORT LENGTH.
Specification
SPECN-ADRDE/SPECN/2002/57 THE TAPE SHALL BE IN CONTINUOUS LENGTH OF 105 M (EXCLUTING SAMPLING ) WITHOUT ANY FLAG OTHERWISE THAT ROLL WILL BE TREATED AS SHORT LENGTH.
