DRIFT PIN TO DS CAT NO. 5120-415474 DES NO.CQA/WPN/1286 PART NO.ICM 2116 (C9045) FOR 30mm CANNON
DC NO. 19175-W DT.21.12.09. FOR DC LATEST TO BE FOLLOWED.
Specification
AS PER DRG TO DRIFT PIN TO DS CAT NO. 5120-415474 DES NO.CQA/WPN/1286 PART NO.ICM 2116 (C9045) FOR 30mm CANNON
DC NO. 19175-W DT.21.12.09. FOR DC LATEST TO BE FOLLOWED.
DRIFT PIN TO DESIGN NO.CQA/WPN/1284 PART NO. ICM 2114 (C9041). REQD FOR 30mm CANNON. DS.CAT.NO.5120-409529.
DC NO.19175-W DT.21.12.09. FOR DC LATEST TO BE FOLLOWED.
Specification
AS PER DRG TO DRIFT PIN TO DESIGN NO.CQA/WPN/1284 PART NO. ICM 2114 (C9041). REQD FOR 30mm CANNON. DS.CAT.NO.5120-409529.
DC NO.19175-W DT.21.12.09. FOR DC LATEST TO BE FOLLOWED.
CONVERSION FORGING TO DRG.No.: 64C 2008 200 G3
REQD FOR: OUTER RING TO DRG No.: 2A42.02.008 (C2008)
RAW MATERIAL STEEL ROUND 34mm DIA WILL BE SUPPLIED BY OFT.
Specification
AS PER DRG OF CONVERSION FORGING TO DRG.No.: 64C 2008 200 G3
REQD FOR: OUTER RING TO DRG No.: 2A42.02.008 (C2008)
RAW MATERIAL STEEL ROUND 34mm DIA WILL BE SUPPLIED BY OFT.
LDPE SHEET FOR CAP BALACLAVA OG PEAK INTERLINING FOR ALL SIZES SPECN. NO.1 APPENDIX "B " TO JSS.8405 ;25: 2010 REV NO.1 AMD NO.1&2. AND DRAWING AS PER APPENDIX "B" & "D" RESPECTIVELY PROV. SPECN NO. S/5094/TC/-1 (b)/Cap Bal OG(Imp) AS PER ANNEX "A" ATTACHED AS PER CQA(T&C) CAP QAI NO. CQA(T&C)/QAI/99/TC-11
Specification
LDPE SHEET FOR CAP BALACLAVA OG PEAK INTERLINING FOR ALL SIZES SPECN. NO.1 APPENDIX "B " TO JSS.8405 ;25: 2010 REV NO.1 AMD NO.1&2. AND DRAWING AS PER APPENDIX "B" & "D" RESPECTIVELY PROV. SPECN NO. S/5094/TC/-1 (b)/Cap Bal OG(Imp) AS PER ANNEX "A" ATTACHED AS PER CQA(T&C) CAP QAI NO. CQA(T&C)/QAI/99/TC-11
As per Supp. Schedule No.Tex-1/1299/82/1 Appendix B to Prov. Specification No. S/2590/Cap FS Army Logo/TC-15(a) and dimensions as per Drawing Sheet with Prov. Specification No .S/2590 /Cap FS Army Logo/TC-15(a).
Specification
As per Supp. Schedule No.Tex-1/1299/82/1 Appendix B to Prov. Specification No. S/2590/Cap FS Army Logo/TC-15(a) and dimensions as per Drawing Sheet with Prov. Specification No .S/2590 /Cap FS Army Logo/TC-15(a).
LEVER,TRIPPING TO DS CAT NO. 5340-016094 ( LT.DC- 26827 SADT.10-5-2016).MACRO ETCH TEST TO ASTME 381-84 WILL BE AS PERCOL.(C) OF SL. NO.1 OF CQA(SA) NOTE SHEET NO.1.NMIR TEST TO IS:4163-82 WILL BE AS PER COL.(C) OF SL. NO.3OF CQA(SA) NOTE SHEET NO.1
Specification
LEVER,TRIPPING TO DS CAT NO. 5340-016094 ( LT.DC- 26827 SADT.10-5-2016).MACRO ETCH TEST TO ASTME 381-84 WILL BE AS PERCOL.(C) OF SL. NO.1 OF CQA(SA) NOTE SHEET NO.1.NMIR TEST TO IS:4163-82 WILL BE AS PER COL.(C) OF SL. NO.3OF CQA(SA) NOTE SHEET NO.1
IND/ADE/0087 (a) Except That
1-Weight, gsm – A tolerance of +-10% shall be applicable to 407 gsm after waterproofing.
2-Count of yarn :-Warp :-2 ply of 20s Single yarn
Weft :-3 ply of 24s Single yarn
(Note: The count of single yarn is approximate and given for the guidance of the manufacturers. The no. of plies, however, shall not be changed.)
3-No. of threads/ inch:- Warp:-92 Weft:-48
(The tolerance in no. of threads/inch shall be +- 5%)
4-Shade OD (Olive Drab), Shade No. 298 as per IS:5
COTTON FABRIC FOR S.D. PARACHUTE type II of IS:2970-1987 Reffirmed 2004 There shall be no presence of starch in appearance workmanship and finish and other respects not denined in the specification the material shall conform to the sealed pattern held in the custody of CQAT&C Kanpur. The bolt length/Roll length 40.00 Mtr. or above.
2.PACKING AND MARKING : As per relevant clause of specn.
AS PER TECH.PARTICULARS
(a) MASS/SQ MET : 58 GM (MAX)
(b) BREAKING STRENGTH, BOTH WAYS : 60 KGF (MIN)
(c) TEARING STRENGTH, BOTH WAYS : 1.7 KGF (MIN)
(d) AIR POROSITY : 7-10 CU.FT/SQ.FT/SEC.
(e) THICKNESS:0.11MM,MAX AT A PRESSUE OF 200GM/SQCM.
(f) WIDTH : 100 CM
(g) YARN LENIER DENSITY, BOTHWAYS : 45 DENIER(NORMAL)
(h) TWIST OF YARN :WARP:200 TPM, WEFT: 150TPM
(i) THREAD DENSITY, BOTHWAYS :48-50/CM.(j) WEAVE:2/1 TWILL
NOTE: THERE SHOULD NOT BE ANY TYPE OF YARN DISTORTION/SLIPPAG
SPECN-AS PER PARTICULARS.
(a) MASS/MET. :33 GM(MAX)
(b)BREAKING STRENGTH(BOTHWAYS) :38 KGF(MIN)TESTING METHOD OF
B.S.IS:1969-1968
(c)TEARING STRENGTH(BOTHWAYS) :1.7KGF(MIN)
TESTING METHOD OF TEARING STRENGTH IS:4726-1964 APP.'D'.
(d)AIRPOROSITY:16-22CV.FT/SQ.FT/SEC. (e)THICKNESS:0.07MM(MAX) AT PRESSURE 200GM/SQCM
(f)WIDTH: 100 CM.
(g)WEAVE :PLAIN
(h)YARN LINEAR DENSITY BOTHWAYS:30 DENIER(NOMINAL)
(i)TWIST OF YARN :WARP:200TPM, WEFT:SPIN(10-30 TPM)
(j)THREAD DENSITY BOTHWAYS :44-45 PER CM.
THERE SHOULD NOT BE ANY YARN DISTORTION/SLIPPAGE IN FABRIC
SPCN: ADRDE/SPECN/1980/5(a)In appearance, workmanship, feel, finish and others respects not defined in the specification the material shall conform to the sealed pattern held in the
custody of controller CQAT&C Kanpur and in addition the firm shall get, The name and/or trade mark woven/stamped along with selvedge at the interval of one meter on either side of the
fabric. (2)Packing & Marking:-as per relevant clause of specification. (3)Sampling plan:-As per relevant clause of specification
